TRENDnet User’s Guide
TV-IP572W / TV-IP572WI
34
802.11g: 15dBm (typical)
802.11n: 14dBm (typical)
Receiving Sensitivity
802.11b: -88dBm at 11Mbps
802.11g: -74dBm at 54Mbps
802.11n: -68dBm at 150Mbps
Channels
1~11 (FCC), 1~13(ETSI)
Management
Accounts
Up to 64 user accounts
Remote Login
Remote management supported
Backup / Restore
Save/retrieve configuration files
Log
System log up to 500 entries
Micro SD
View, download, delete files
Format and remove Micro SD card
Settings
Brightness, contrast, saturation, sharpness, white balance, flip, mirror
(horizontal/vertical), black & white, indoor, outdoor, schedule mode
Shutter: 1/3.25s, 1/7.5s, 1/10s, and 1/15s
Video Setting
Profile 1: H.264/ MPEG-4
- Resolution: 1280 x 800, 640 x 400, 320 x 192, 160 x 96
- Max frame rate: 30fps
Profile 2: H.264/ MPEG-4
- Resolution: 640 x 400, 320 x 192, 160 x 96
- Max frame rate: 30fps
Profile 3: MJPEG
- Resolution: 1280 x 800, 640 x 400, 320 x 192, 160 x 96
- Max frame rate: 1280 x 800 @ 5fps, 640 x 400/320 x 192@30fps
- JPEG quality: Low, Fair, Standard, Good, Excellent
Profile 4: H.264/MPEG-4
- Resolution: 640 x 400, 320 x 192, 160 x 96
- Max frame rate: 30fps
- RTSP: http://ipcamera_ip/3gpp
3GPP
Video codec/MPEG4 (no audio support)
Protocols/RTSP, RTP
Recording
Resolution: Define individual resolution for up to 4 profiles
Required storage: 32MB (minimum per profile)
Recording type: event based (motion detection), continuous, and scheduled
Event Action
Trigger event: motion detection
Action: send real-time snapshot or video recording to FTP or email
Port Settings
HTTP port: 80 (default)
RTSP port: 554 (default)
Time
Synchronize with NTP server or set time / date manually
TV-IP572WI
Camera
General
Sensor: 1/4” CMOS Sensor
Board Lens
Focal Length: 4mm
F/No: 1.5
Minimum illumination: 0 lux
Focus Depth: 20 cm ~ infinity
View:
Horizontal: 51.8 degrees
Vertical: 33.8 degrees
Diagonal: 59.6 degrees
Digital Zoom: 4x
Audio
Built-in omni-directional microphone
Sensitivity: -40dB +/- 3dB (5 meters max.)
Frequency: 100~20000Hz
S/N: >60dB
Format: PCM/ADPCM
External speaker output (speaker sold separately)
Two-way audio with echo canceling
Day/Night
Built-in ICR
Night vision (IR) supports up to 7.5 meters
Hardware
Network
IEEE 802.3u 10/100Mbps Auto-MDIX Fast Ethernet
LED
Power, Link/Act
SD slot
Supports Micro SD (up to 32GB)
