ON Battery Events

ThisfeatureallowstheusertoviewthenumberoftimestheUPShasexperiencedanONBattery

Event. To reset the counter to “0,” press and hold the button.

Basic Operation continued

Tap the buttonrepeatedlytoadvancetotheONBatteryEventsdisplay,asshownabove.

Note: The value displayed is a random value used for example reference.

AVR Events

ThisfeatureallowstheusertoviewthenumberoftimestheUPShasexperiencedanAutomatic

VoltageRegulationEvent.Toresetthecounterto“0,”pressandholdthe button.

Tap the buttonrepeatedlytoadvancetotheAVRdisplay,asshownabove.

Note: The value displayed is a random value used for example reference.

Power Sensitivity

Thissettingisnormallysetto100%,whichenablestheUPStoprotectagainstwaveformdistortions

initsACinput.Whensuchdistortionoccurs,theUPSwillnormallyswitchtoprovidingpuresinewave

powerfromitsbatteryreservesforaslongasthedistortionispresent.Insomeareaswithpoorutility

powerorwheretheUPS’sinputpowercomesfromabackupgenerator,frequentbrownoutsand/or

chronicwaveformdistortioncouldcausetheUPStoswitchtobatterytoooften,drainingitsbattery

reserves. Youmay beable toreduce howoftenyour UPSswitches tobattery duetowaveform

distortionorbrownoutsbyexperimentingwithdifferentsettings.Asthesettingisreduced,theUPS

becomes more tolerant of variations in its input power’s AC waveform.

Note: When experimenting with different settings, operate connected equipment in a safe test mode so that the

effect on the equipment of any waveform distortions in the UPS’s output can be evaluated without disrupting critical

operations. The experiment should last long enough to assure that all expected line conditions are encountered.
