VX-8R OPERATING MANUAL74
Press the key, then rotate the DIAL knob to select the
“
POWRPOWR
POWRPOWR
POWR” parameter to “
OFFOFF
OFFOFF
OFF”.
8. Press the PTT switch of the VX-8R to save the new setting
and return to normal operation.
OPERATION
1. When the BH-1
(
or BH-2
)
is correctly recognized by the VX-8R, “ ” icon will
appear on the display of the VX-8R and the LED indicator of the BH-1
(
or BH-2
)
will blink blue.
2. Adjust the receiver audio level using the
[
VOLUME
(
+
)]
/
[
VOLUME
(–)]
switches on
the BH-1
(
or BH-2
)
. Pressing the
[
VOLUME
(
+
)]
switch increases the receiver audio
level. Pressing the
[
VOLUME
(–)]
switch decreases the receiver audio level.
3. Press the PTT switch on the BH-1
(
or BH-2
)
to transmit. Release the PTT switch to
return to receive.
4. You may adjust the microphone gain (Five steps) of the BH-2 by pressing the
[
VOL-
UME
(
+
)]
/
[
VOLUME
(–)]
switch while pressing and holding the PTT switch, if de-
sired.
Pressing the
[
VOLUME
(
+
)]
switch while pressing and holding the PTT switch in-
creases the microphone level. Pressing the
[
VOLUME
(–)]
switch while pressing and
holding the PTT switch decreases the microphone level. When the microphone gain
reaches maximum or minimum, a beep will be heard in the BH-2 speaker.
5. The communication range between the BH-1
(
or BH-2
)
and VX-8R is around 1 m (3
ft). If you move out of range, a beep will be heard from the BH-1
(
or BH-2
)
to alert
you. If you move back into range, the BH-1
(
or BH-2
)
will beep to alert you that you
are back within range.
6. When the battery voltage of the BH-1
(
or BH-2
)
is low;
a. the LED will blink Red and Blue.
b. a beep will be heard from the BH-1
(
or BH-2
)
.
c. the “ ” icon on the VX-8R will be blinking fast.
Charge the BH-1’s
(
or BH-2’s
)
battery with the optional CD-40 Charger Cradle.
When the BH-1 (or BH-2) is correctly recognized, the VX-8R’s internal speaker and
microphone are disabled.
Bluetooth
®
OPERATION
OPERATING BAND
BH-1/BH-2 BATTERY LIFE
BATTERY LIFE
(
APPROX.
)
BH-2
6 hours
Battery Saver “ON”: 20 hours
Battery Saver “OFF”: 3 hours
BH-1
3 hours
Battery Saver “ON”: 10 hours
Battery Saver “OFF”: 3 hours
AM/FM Broadcast Band
Amateur Band
(
1:1:8 TX:RX:Standby
)
