Viking Technology viking Manual

A SERVICE OF

next previous

Manual

7/24/2014

PSFEM2xxxGRxxx

Viking Technology

Revision A10

Page 7 of 43

www.vikingtechnology.com

Table of Contents

1 INTRODUCTION 10

1.1 Features 10

1.2 Block Diagram 11

1.3 SATA Interface 12

2 PRODUCT SPECIFICATIONS 13

2.1 Performance 13

2.2 Timing 13

2.2.1 STANDBY IMMEDIATE Command 13

2.3 Electrical Characteristics 14

2.3.1 Absolute Maximum Ratings 14

2.3.2 Supply Voltage 14

2.3.3 Supply Current 15

2.3.4 Power Consumption 15

2.4 Environmental Conditions 15

2.4.1 Temperature and Altitude 15

2.4.2 Shock and Vibration 16

2.4.3 Electromagnetic Immunity 16

2.5 Reliability 16

2.6 Data Security 16

2.6.1 Quick Erase 17

2.6.2 Military Secure Erase / Sanitization/ Purge Routines 17

3 MECHANICAL INFORMATION 26

3.1 mSATA SSD Weight 29

4 PIN AND SIGNAL DESCRIPTIONS 29

4.1 Signal and Power Description Tables 29

4.2 Hot Plug Support 30

5 COMMAND SETS 30
