Recording
Benefits of the DDX3216
16 high-grade 24-bit converters and 32-bit internal processing for highest
dynamic resolution.
There is no need to leave the digital domain after the initial A/D conversion, as
no additional A/D and D/A conversion stages are required. Thus, maximum
audio quality is retained.
The busses allow you to record 16 signals at the same time. Along with the four
multi outputs, this gives you 20 channels for simultaneous multi-track recording.
128 snapshot memories enable you to work on several projects simultaneously.
With the help of the dynamic automation feature, a single operator can conduct
complex recording scenarios.
The 4 multi outputs can be used for quick and easy creation of monitor mixes.
The four built-in, fully editable effects processors with 26 programmable algo-
rithms allow purely digital effects processing and are simultaneously accessi-
ble from all 32 channels.
Compressor/limiter, gate and sweepable high-pass filter for all 32 channels.
Fader and mute groups make it easier to operate several channels simultaneously.
The first 16 channels offer up to 276 ms of delay for run-time compensation
or effects.
Remote control of multi-track recorders is possible via MMC.
The built-in meter bridge gives you full control over all input signal levels.
Inserts on the first 12 channels allow you to integrate external analog gear.
Hints
Channels 1 through 12 provide high-grade microphone preamps with switch-
able phantom power for condenser microphones.
Use the multi outputs for monitor mixes in the studio.
Set the input levels on the analog inputs as high as possible to ensure
maximum dynamics.
➤
➤
➤
➤
➤
➤
➤
➤
➤
➤
➤
➤
➤
➤
➤
➤
