13 X V-AMP LX1-X User Manual
9. Specications
Instrument Input
Type ¼" TS connector, unbalanced
Input impedance approx. 1 MΩ
Max. input level +5 dBu
Line/Headphone Output
Type ¼" TRS stereo connector, balanced
Output impedance approx. 50 Ω
Max. output level +13 dBu @ 10 kΩ / +18 dBm @ 100 Ω
Mono Amp Output
Type ¼" TS connector, unbalanced
Output impedance approx. 100 Ω
Max. output level -7 dBu
Digital Signal Processing
Converter 24-bit Delta-Sigma,
64/128-times oversampling
Dynamics A/D 100 dB @ preamp bypass
Dynamics D/A 95 dB
Sample rate 31.250 kHz
DSP 100 Mips
Delay time max. 1960 ms stereo
Run time approx. 5 ms
(Line In >> Line Out)
Display
Type 2-digit, 7-segment LED display
Power Supply
Mains voltage
USA/Canada 120 V~, 60 Hz
U.K./Australia 240 V~, 50 Hz
China/Korea 220 V~, 50 Hz
Europe 230 V~, 50 Hz
Japan 100 V~, 50 - 60 Hz
Power consumption max. 7 W
Mains connection external power supply (2-pole)
Dimensions/Weight
Dimensions (H x W x D) approx. 1.97 x 9.25 x 6.89"
approx. 50 x 235 x 175 mm
Weight approx. 1.76 lbs / 0.80 kg
Shipping weight approx. 4.40 lbs / 2 kg
BEHRINGER constantly strives to maintain the highest quality standards. Modifications may be made,
if necessary, without prior notice. The specifications and appearance of the equipment may therefore differ from
those listed or illustrated.
