260BAY Rev. A, 6/07
1 of 7
Installation Instructions
Gas Stacking Stand Mounting Kit, P/N 111467G
for Two Gas SteamChef 22CGT3 or 22CGT6 Steamers
Mounted on an ES263044 Equipment Stand
This kit is for mounting (2) SteamChef 22CGT3.1 or 6.1 steamers on an ES263044 Equipment Stand.
The Installation of Cleveland Range steamers on the ES263044 Equipment Stand should only be performed
by Cleveland Range authorized technicians.
Read the entire installation procedure before beginning.
The installer must be familiar with this procedure, and the instructions supplied with each SteamChef Steamer,
Cleveland Range P/N 22CGT-INM and P/N 22CGT-OPM.
Item Number
on Drawings
Quantity Part Number Description
- 1 112523 WARNING LABEL, BURN AND SCALD HAZARD (SEE FIG. 2)
22 3 19148 SCREW, HEX WASHER HD, #10 X 1/2 , TYPE AB, ZINC PLTD
21 1 111401 FLUE RISER ASSY, CHEF 6
20 1 112488 ASSEMBLY, FLUE ADAPTER
19 7 108734 NUT, “U” TYPE (EXTRUDED) #10-24 UNC-2B THREAD
18 8 101231 SCREW, 10-24 X 0.500 SST, PHILLIPS TRUSS HEAD
17 1 112490 ASSEMBLY, REAR FLUE COVER
16 1 112489 COVER, FLUE ADAPTER, FRONT
15 4 110921 FITTING, 1/4 – 18 NPTF X 3/4 – 11.5 NH, BRASS
14 2 111000 FITTING, WYE, GHTF X (2) GHTM, BRASS
13 4 110987 STRAINER, FILTER WASHER, GARDEN HOSE INLET (GHT)
12 2 111160 HOSE ASSEMBLY, GHT (F) X 39” LONG
11 1 05265 ELBOW, 90, 1” NPT, BLK
10 1 1054693000 HOSE, BLACK EPDM, 1” ID X 30” LONG
9 2 03204 CLAMP, HOSE, WORM DRIVE, .812-1.50 DIA
8 2 14481 FITTING, 1” HOSE X 1” NPT (M)
7 1 20221 TEE, 1 1/2” NPT, BLK
6 2 02573 BUSHING, HEX, 1” NPT X 1-1/2” NPT, BLK
5 2 109268 NIPPLE, 1” NPT X 3-1/2” LONG, BLK, TBE
4 4 111013 WASHER, FENDER, 17/32” ID X 1.5” OD
3 4 23153 WASHER, LOCK, 1/2", SST
2 4 111012 SCREW, 1/2 – 13 , HEX HEAD
1 1 ES263044 EQUIPMENT STAND, ASSEMBLY, STACKED
