www.crateamps.com
©2001 SLM ELECTRONICS, A DIVISION OF ST. LOUIS MUSIC, 1400 FERGUSON, ST. LOUIS, MO. 63133
P/N 47-453-01 • 07/01
GFX-15 Amplifier
Crate continually develops new products, as well as improves existing ones. For this reason, the
specifications and information in this Crate manual are subject to change without notice.
Output Power Rating 12 watts RMS @ 5% THD 4 ohms, 120VAC
Gain, Overdrive Channel 86dB +/-6dB @ 1kHz
Gain, Clean Channel 46dB +/-6dB @ 1kHz
Tone Control Range, Low 25dB @ 80Hz
Tone Control Range, Mid 19dB @ 900Hz
Tone Control Range, High 23dB @ 5kHz
Signal To Noise, Overdrive Channel >50dB
Signal To Noise, Clean Channel >65dB
Maximum Signal Accepted 2.2 volts RMS min. @ 400Hz
Internal Speaker 8” Crate Custom Design 4 ohm
Input Power Requirements 120 VAC, 60Hz, 30VA
100/115VAC, 50/60Hz, 30VA
230VAC, 50/60Hz, 30VA
Size and Weight: 13” H x 13.63” W x 8.25” D, 15 lbs.
The GFX-15 is covered with a durable black Tolex material: wipe it
clean with a lint-free cloth. Never spray cleaning agents onto the
cabinet. Avoid abrasive cleansers which could damage the finish.
GFX-15 TECHNICAL SPECIFICATIONS
Declaration Of Conformity
#33, Effective 01-01-2001
Manufacturer’s Name: SLM Electronics
Production Facility: 11880 Borman Drive, St. Louis, MO 63146, USA
Production Facility: 700 Hwy 202 W, Yellville, AR 72687, USA
Shipping Facility: 1400 Ferguson Ave., St. Louis, MO 63133, USA
Office Facility: 1400 Ferguson Ave., St. Louis, MO 63133, USA
Product Type: Audio Amplifier
Complies with Standards:
LVD: 92/31/EEC, 93/68/EEC, & 73/23/EWG
Safety: EN60065
EMC: EN55013, EN55020, EN55022, EN61000-3-2,
& EN61000-3-3
Supplementary information provided by your local Sales & Services Office or:
SLM Electronics - R & D Engineering
1901 Congressional Drive, St Louis, MO 63146, USA
Tel.: 314-569-0141, Fax: 314-569-0175
