Output Power Rating 50W RMS @ 10% THD, 8 ohm load, 120 VAC
Input Impedance 1M ohm
Maximum Signal Accepted 2.8V peak to peak
Signal To Noise Ratio Channel B: 52dB
Channel A: 58dB
Gain Channel B: 75dB
Channel A: 68dB
Tone Control Range Channel B: Bass: 12dB, 60Hz
Mid: 10dB, 600Hz
Treble: 7dB, 4kHz
Channel A: Bass: 20dB, 70Hz
Treble: 16dB, 2kHz
Line Out Level 375mV RMS @ full power output
Tube Type Preamp: (4) 12AX7 Power Amp: (4) EL84/6BQ5
Power Requirements 120VAC, 60Hz, 110VA
100/115VAC, 50/60Hz, 110VA
230VAC, 50/60Hz, 110VA
Size and Weight 11”H x 21.25”W x 11.25”D, 35 lbs.
©1998 SLM ELECTRONICS • A division of St. Louis Music • 1400 Ferguson Avenue • St. Louis, Mo 63133
P/N 47-547-12 • 02/98
TECHNICAL SPECIFICATIONS:
The GT-500H is covered with a durable black Tolex
®
material. To keep the cabinet in top condition,
wipe it clean with a damp lint-free cloth to remove dirt and road film. Never spray cleaning agents
directly onto the cabinet, and stay away from abrasive cleansers which could damage the finish.
Crate continually develops new products, as well as improves existing ones.
For this reason, the specifications and information in this publication
are subject to change without notice.
GT-500H Amplifier
