19. PRE AMP OUT: Use this jack to send a high impedance unbalanced signal from the amplifier to
another amplifier or recording device by means of a shielded signal cable.
20. POWER AMP IN: Use this jack to connect a line level signal directly into the internal power amp
circuit. When a connector is inserted into this jack, the signals from channels 1-4 are disabled.
21. BAL. LINE OUT: Use this XLR jack to send a balanced line level signal from the amplifier to an
external amplifier, mixing console, or recording device by means of a balanced shielded signal cable.
22. (HEADPHONES): Use this jack to connect a pair of headphones to the amplifier. The signal
at this jack is adjusted by the Bal. Line Out / Headphones Level control (#14). The internal speakers
are not disconnected when headphones are used. Turn the Master Level control (#12) down for “pri-
vate” practice sessions.
CAUTION: To avoid possible damage to your hearing, do not use headphones for extended
periods of time at extremely loud levels.
23. CD INPUT: Use these RCA jacks to connect the output from a CD player or tape deck to the ampli-
fier. The signal at these jacks is combined into a mono signal which is sent to the internal power amp
circuit. Use the CD or tape player’s output level control to adjust the signal for the proper mix with the
other channels.
24. POWER CORD (rear panel, not shown): The grounded power cord should only be plugged into
a grounded power outlet that meets all applicable electrical codes and is compatible with the voltage,
power, and frequency requirements stated on the rear panel. Do not attempt to defeat the safety
ground connection.
6
XK100 Keyboard Amplifier
