Auxiliary/Phrase Mode
Use AUX/Phrase Mode to adjust the AUX IN jack settings (menus 1–2).
Use AUX/Phrase Mode to adjust the Phrase Sampler settings (menus 3–7).
Menu Aux Menu Items Settings—(Function)
1 AUX INPUT LEVEL 1-10 — (Adjusts the volume of whatever you have connected to the AUX IN jacks.)
2 AUX MIX Stereo, Center Cancel, Left, Right — (Helpful for emphasizing or de-emphasizing guitar parts on some recorded material)
3 PHRASE LEVEL 1-10 — (Phrase playback level.)
4 OVERDUB FEEDBACK
1-10 — (Level of previous phrase recorded to new phrase)
5 PHRASE MODE Freeform, Lead In — (Record with or without a lead in. 4 Beat Lead adjusts measure length for correct timing.)
6 PHRASE SOURCE Aux In, Drums, Aux In + Drums, Guitar, All — (Select the source(s) that the Phrase Sampler records.)
NOTE:
To include drums in the sample (Source set to “All”),
start the Drum Loop before you press
Record.
7 PHRASE SPEED Normal, Half Speed — (Phrase playback speed.)
8 PLAYBACK Once, Repeat — (Playback the Phrase one time, or in an endless loop.)
Use FX/Reverb Mode to select a Reverb type (menu 7), and adjust reverb level (menu 8).
Reverb Type Reverb Level
Menu 7 Menu 8
NONE 1-10
AMBIENT 1-10
SMALL ROOM 1-10
LARGE ROOM 1-10
SMALL HALL 1-10
LARGE HALL 1-10
ARENA 1-10
SMALL PLATE 1-10
LARGE PLATE 1-10
SPRING 1-10
63 SPRING 1-10
Drums Mode
Use Drums Mode to select a Drum pattern (first menu), then modify that drum pattern’s settings in menus 2–6.
Menu Drum Menu Items Settings
1 DRUM PATTERN
1 Drop, 12 8met, 16 Hats, 32 Hats, 3 4 Met, 4 4 Met, 5 4 Met, 5 On 4, 50 Shuf, 80 Funk, 80s Hop, Aerwalk, Ballad, Ballad2, Beastly, Bossa, Chicago, Clave, Classic,
Country, Dblkick, Dblshuf, Disco, Dr Hop, Drive, Fever, Fiesta, Funk, Feelin, Grind, Grunge, Halves, Happy, Hardroc, Haze, Hiphop, Hiphop2, Jazz, Kid, Latin,
Latpony, Levee, Lilith, Mambo, Metal, Miami, Modern, Motrcty, Party, Pop, Pop2, Popstar, Punk, Punkpop, Rnb New, Rnb Old, Reggae, Ride, Rock101, Rocbell,
Rocbluz, Rock, Rocker, Rhythm, Rhythm2, Salsa, Samba, Shaker, Shuffle, Ska, Smoke, So Bell, Soul, Speed, Steely, Surftom, Swedes, Swing, Train, Train2, Viking,
Virus, Waltz, Western
2 TEMPO 30-240 Beats per Minute
3 KEY A, A#, B, C, C#, D, D#, E, F, F#, G, G#
4 DRUM LEVEL 1-10
5 BASS LEVEL 1-10
6 ACCOMPANIMENT LEVEL 1-10
FX/Reverb Mode (continued)
