Page 6
SPECIFICATIONS
INPUTS:
DJ Mic.......................................................1.5mV 2 kΩ unbalanced
Phono.............................................................................3mV 47 kΩ
Line...............................................................................150 mV 27 kΩ
OUTPUTS:
Amp/Booth....................................................................0 dB 775mV 400 Ω
Max...............................................................................24V Peak-to-Peak
Rec..................................................................................225mV 5 kΩ
SAMPLER:
Sampler System.................................................................12 Bit Sampling
Sample Length ............................................................12 Seconds
Total Memory Capacity ................................................................1 Mbit
GENERAL:
Low .....................................................................+ 12dB/- 32 dB
Mid ..........................................................................+ 12dB/- 32 dB
High..................................................................+ 12dB/- 32 dB
Gain (Mic).......................................................................0 to -40dB
Gain (Chnls 1-3).......................................................................0 to -20dB
Frequency Response............................................20Hz - 20kHz +/- 2dB
Distortion............................................................................less than 0.02%
S/N Ratio..........................................................................better than 80dB
Talkover Attenuation........................................................................16dB
Power Source...................................................115/230V 50/60Hz 15W
Dimensions................................................254mmW x 305mmD x 112mmH
10”W x 12”D x 4 7/16”H
Weight........................................................................................6.5 lbs(3 Kg)
