TASCAM FW-1804 3
Introduction
CAUTION
• Always perform all FireWire connections and disconnec-
tions with the power to both the FW-1804 and the com-
puter turned off. If connections are made or broken with
power to the FW-1804 or computer turned on, this may
result in your computer crashing, or "freezing" and pos-
sible loss of data.
There are two types of connector that may be used with
IEEE 1394 devices. One is a 6-pin connector, and the other
is a 4-pin connector (the difference between them is that the
6-pin connector carries power which can power external
devices).
The cable supplied with the FW-1804 is 6-pin to 6-pin—
some computers are only fitted with a 4-pin IEEE 1394
connector, and we recommend that you use a computer
with a 6-pin IEEE 1394 connector.
NOTE
• Although an IEEE 1394 connection can supply power to
some types of device, it is not possible to use such a con-
nection to power the FW-1804.
• Ensure that the cable is plugged in right side up by sight,
not just by feel. Forcing the cable in upside down will
damage the FW-1804.
Before Installing the Software
The normal precautions apply when setting up the FW-
1804:
• Make all (computer, audio and MIDI) connections to the
FW-1804 with the power turned off. See "Connections"
on page 8 for details of how to make connections.
• Do not connect the FW-1804 to the computer until you
have installed the software.
• Handle the enclosed CD-ROM with care. If it becomes
dirty or scratched, it will be impossible for a computer to
read it, and the software cannot be installed. If the disc
becomes unreadable, a charge will be made for its
replacement, but software and documentation can be
downloaded from the TASCAM Web site.
• Do not attempt to play the enclosed CD-ROM using an
audio CD player, as this may cause damage to hearing,
as well as to speakers, etc.
