TASCAM VL-X5 Owner's Manual 7
Placing the VL-X5
Placing the VL-X5
Placing the speakers is one of the most important procedures to monitor correct sound.
To monitor with VL-X5 at its maximum capability, appropriate listening environment and correct placement are
required. Please, refer to the following to place the VL-X5 correctly.
60 cm
40 cm
Left Right
1 VL-X5's set up position is 60 cm
(Recommendation 100 cm) to the back and
40cm (Recommendation 60 cm) to the side.
2 Basically, two units and the listener should align to
from a regular triangle.
3 The height of units, more precisely, the top of the
woofer should come up to where your ears are in
normal listening environment.
4 Recommend Place the VL-X5 horizontally. If you
Placing VL-X5 horizontally, refer to the following
diagram.
NOTE
DO NOT place any obstacles that may block the flow of air, which is medium of the sound, or
create reflected sound, especially, the material of high reflection tendency including glass, mirror
or metal. Place those materials away from the path of the sound from VL-X5.
