Parts List
12
Assembly Part Part
Key No. Number Description Carton 1 Carton 2 Carton 3 Carton 4
1 7855 Truss Lower Chord 2
2 7856 Truss Upper Chord 2
3 6382 Center Gable Brace 2 8
4 7739 Truss Diagonal 4
5 6381 Mid Gable Brace 4 4
6 6380 Outer Gable Brace 4 4
7 7738 Splice Plate 1
8 7834 Right Front Frame 3
9 7837 Side Frame 4
10 7914 Side Frame 4
11 8532 Right Rear Frame 3
12 8531 Left Rear Frame 3
13 7835 Left Front Frame 3
14 7857 Truss Support 2 2
15 7824 Corner Wall Panel 4
16 7825 Front Wall Panel 2
17 7822 Main Wall Panel 7 6
18 6228 Frame Support 4
19 7917 Truss Column 2
20 7839 Front Column 2
21 7831 Lintel 1
22 7915 Side Top Angle 2
23 7838 Side Top Angle 2
24 7823 Medium Wall Panel 1
25 7833 Roof Beam 6
26 7912 Roof Beam 6
27 7942 Right Gable 2
28 7943 Left Gable 2
29 7840 Right Track Support 1
30 7841 Left Track Support 1
31 6372 Gable Strut 2 2
32 7827 Left Roof Panel 2
33 7826 Right Roof Panel 2
34 7828 Middle Roof Panel 4 6
35 7843 Ridge Cap 1 1
36 6874 Ridge Cap 1
37 5220 Side Roof Trim 2 2
38 6014 Side Roof Trim 2
39 7845 Left Rake 2
40 7846 Right Rake 2
41 7913 Spring Support Bracket 2
42 7830 Right Door Jamb 1
43 7829 Left Door Jamb 1
44 7517 Lower Door Track 1
45 7560 Ramp 1
46 7950 Side Wall Channel 1
47 7949 Side Wall Channel 1
48 7951 Support Column 1
49 7958 Door Track 1
50 7946 Door Jamb 2
51 7948 Door Wall Brace 1
52 7945 Door 1
53 3719 Door Handle Brace 1
54 7947 Vertical Door Brace 1
55 6264 Horizontal Door Brace 2
56 8530 Splice Channel 1
57 9286 Door Panel (Bottom) 1
58 7808 Bottom Angle 1
59 8198 Vinyl Weatherstrip 1
60 7848 Door Panel (Lock) 1
61 67510 Right Vertical Track 1
62 67509 Left Vertical Track 1
63 67476 Right Horizontal Tack 1
64 67475 Left Horizontal Track 1
65 7847 Door Panel (Top) 1
Carton #4 of the VT1217 can be deleted for a complete 12'x10' building, or more than one carton #4 may be used to extend depth in multiples of 7'.
