3-13 Merging raster files with DocBuilder
TO VIEW AND EDIT RASTER DATA JOBS:
1. Select a raster data job and choose Thumbnail A from the Job menu.
The file must be a held raster job in the RIP area.
2. In the Thumbnail A window, right-click a thumbnail image to see the
commands available for pages in Thumbnail A.
These commands can also be accessed from the Page menu (see page 2-9) as
well as from buttons along the left side of the Thumbnail A window (see
illustration on page 3-13).
To scroll through the pages in Thumbnail A, you can drag the slider bar at
the bottom of the screen, click in the empty area to the left or right of the
slider bar, or click on the arrows.
Delete deletes the currently selected page.
Duplicate duplicates the currently selected page.
Undo undoes the previous DocBuilder command—this command is available
only from the Page menu.
3. To move pages within Thumbnail A, left-click to select the page(s) and hold
down the mouse button as you drag the selected page(s) to the new location.
Shift-click to select multiple, sequential pages; Ctrl-click to select multiple,
non-sequential pages.
If you move the page(s) on top of existing page(s), the page(s) will be
overwritten.
Click to duplicate a page
Click to delete a page
