Specifications B–3
Table B–1 14-Disk Enclosure Physical Specification
Horizontal Orientation (see Figure B–1) Vertical Orientation (see Figure B–2)
Empty Installed Shipping Carton Shipping Carton and
Pallet
5.16 in (13.1 cm) 5.16 in (13.1 cm) 25.25 in (64.1 cm) 30.25 in (76.8 cm)
17.625 in (44.8 cm) 17.625 in (44.8 cm) 23.5 in (59.7cm) 40.0 in (101.6 cm)
19.875 in (50.5cm) 19.875 in (50.5cm 12.5 in (31.8 cm) 24 in (61 cm)
Weight 24 lb (11 kg) 68 lb (31 kg) 96 lb (44 kg) 108 lb (49 kg)
Table B–2 Element Physical Specifications
Vertical Orientation (see Figure B–2) Horizontal Orientation (see Figure B–1)
Installed Shipping Carton
Environmental Monitoring Unit (EMU)
4.5 in (11.4 cm) 8.5 in (21.6 cm)
9.5 in (24.1 cm) 13.0 in (33.0 cm)
1.375 in (3.5 cm) 4.5 in (11.4 cm)
Weight 1.3 lb (0.6 kg) 2.3 lb (1.0 kg)
Variable Speed Fan (without power supply)
5.5 in (14.0 cm) 7.5 in (19.0 cm)
3.25 in (6.4 cm) 8.75 in (22.2 cm)
6.25 in (15.9 cm) 8.0 in (20.3 cm)
Weight 1.0 lb (0.5 kg) 2.0 lb (0.9 kg)
I/O Module
4.5 in (12.7 cm) 8.5 in (21.6 cm)
9.5 in (24.1 cm) 13.0 in (33.0 cm)
1.625 in (4.1 cm) 4.5 in (11.4 cm)
Weight 1.3 lb (0.6 kg) 2.3 lb (1.0 kg)
