DATALOGIC MEMOR™
1 3
3.2 DATA CAPTURE
To capture data first of all select the barcode icon on the bottom-right side of the
display and tap the 'Capture' menu item then proceed with the following
directions.
To configure and enable data capture parameters refer to par. 3.5.
3.2.1 Laser Data Capture
To scan barcodes, point the Datalogic Memor™ laser model onto the code from
a distance within the reading range while pressing the SCAN key.
The lighted band emitted by the laser must completely intercept the barcode as
shown in the figure below. If enabled, the emission of an acoustic signal will
indicate that the scan has taken place correctly.
NOTE
Remove the protective film cover over the Laser Output
Window before use.
16
