FENIX IMVICO
TK14 OPERATION MANUAL
32/65
n
= <02>H:
Offline status
Bit OFF/ON Function
0 OFF Not used. Fixed to OFF
1 ON Not used. Fixed to ON
OFF Platen is closed (Thermal head is closed)
2
ON Platen is open (Thermal head is open)
3 - Undefined
4 ON Not used. Fixed to ON
OFF No paper-end stop
5
ON Printing is being stopped
OFF No error
6
ON Error occurred
7 OFF Not used. Fixed to OFF
n
= <03>H:
Error status
Bit OFF/ON Function
0 OFF Not used. Fixed to OFF
1 ON Not used. Fixed to ON
2 OFF Not used. Fixed to OFF
3 x Not used.
4 ON Not used. Fixed to ON
OFF No unrecoverable error
5
ON Unrecoverable error occurred
OFF No auto-recoverable error
6
ON Auto-recoverable error occurred
7 OFF Not used. Fixed to OFF
Bit 6: Bit 6 is ON when printing is stopped due to high print head temperature
until the print head temperature drops sufficiently.
n
= <04>H:
Continuous paper sensor status
Bit OFF/ON Function
0 OFF Not used. Fixed to OFF
1 ON Not used. Fixed to ON
2 - Undefined
OFF Paper near-end sensor: Paper present
3
ON Paper near-end sensor: Paper not
present
4 ON Not used. Fixed to ON
5 - Undefined
OFF Paper real-end sensor: Paper present
6
Paper real-end sensor: Paper not present
7 OFF Not used. Fixed to OFF
n = <05>H:
Paper sensor status
Bit OFF/ON Function
0 OFF Not used. Fixed to OFF
1 ON Not used. Fixed to ON
2 - Undefined
OFF Ticket not pick up
3
ON Ticket pick up
4 ON Not used. Fixed to ON
5 - Undefined
6 - Undefined
7 OFF Not used. Fixed to OFF
