FCO in Open Position
Figure 6-11 Fibre Channel Option in the Open Position
7. Connect the AUXPWR cable to the AUXPWR connector on the Executive PCBA
and to the PWRIN connector on the Fibre Channel Option. See Figure 6-12 and
Figure 6-14.
501440 Rev. G FCO Type C Installation 6-13
