EUROPOWER PMP1000/PMP3000/PMP5000
2 CONTROL ELEMENTS
2.3 Effects section
List of all multi-effects processor presets.
The LED level meter on the effects module should always
show a sufficiently high level. Make sure that the Clip LED
illuminates with signal peaks only. If it is constantly illu-
minated, the effects processor is overloading, which can
lead to unpleasant distortion. The FX SEND fader (
PMP1000)
or FX/FX 1/2 fader (
PMP3000/PMP5000) controls the level
sent to the effects module and to the FX SEND output
jacks.
The effects display always reads the currently selected
preset.
PMP3000/PMP5000: Press the FX1/2 IN switch to activate
the effects processor.
PMP1000/PMP3000: Turn the PROGRAM control to select
an effects algorithm (preset number starts flashing). Press
this control to activate the effect selected (PMP5000:
FX 1/2 (PUSH)).
PMP1000: The effects processor is operative all the
time. Adjust the effect intensity for the MAIN or
MON signals with controls
or respectively.
PMP5000: The PMP5000 has two separate effects
processors, which can be used independently of one
another. Enable one or both processors with the FX1/2 IN
buttons.
PMP3000/PMP5000: The FX 1/2 TO MON 1 control allows
you to set the intensity of the multi-effects processors in
the monitor mix. No effect is sent to the monitor mix when
this control is set fully counter-clockwise.
PMP1000: The FX TO MON control performs the same
function as on the PMP3000 and PMP5000.
The FX 1/2 TO MON 2 control allows you to determine the
effect intensity of the multi-effects processor in the monitor
2 mix. No effect is sent to the monitor 2 mix with this control
turned fully counter-clockwise.
The FX 1/2 TO MAIN control allows you to determine the
effect intensity of the multi-effects processor in the main
mix. No effect is sent to the main mix with this control
turned fully counter-clockwise.
PMP1000: The FX TO MAIN control performs the same
function as on the PMP3000 and PMP5000.
2.4 Main and monitor section
The SURROUND control determines the
effect intensity. This is a built-in effect, which
widens the stereo panorama, thus making
the sound more lively and transparent.
Press the XPQ TO MAIN switch to activate this effect.
Pressing the AFL switch (after-fader listening) activates
the solo function. If AFL is on for the corresponding channel
in the main section, you will only hear the signal from this
channel. Its volume can be adjusted with the fader.
Switching AFL on has no effect on the main or monitor mix,
as long as you don’t move the fader. In this way, you can
monitor one or several selected signals via the PHONES/
CTRL jack
. When AFL is on, the corresponding control
LED illuminates.
The PMP1000 does not have an AFL function.
PMP1000: FX SEND fader.
PMP3000: FX fader.
PMP5000: FX 1/2 fader.
This is the master send fader for the signal routed to the
effects processor and to the FX SEND output
(see
also
and ).
PMP1000: MON SEND fader.
PMP3000/PMP5000: MON 1/2 fader.
These faders are used to set the monitor output volume
(see also
and ).
PMP1000: The main mix allows you to control the volume
from the Main 1 output with both faders.
PMP3000/PMP5000: The MAIN 1 fader controls the volume
of the EUROPOWER. The main signal is also provided at the
MAIN 1 output (see also
).
PMP3000/PMP5000: The MONO fader controls the mono
mix signal (see also
).
PMP5000: The SUB FILTER filters out frequencies above
the selected setting, so that only low frequencies are sent
to an (active) subwoofer via the MONO OUT
). Set this
switch to “On” to activate the filter.
PMP5000: The SUB FREQ control determines the cut-off
frequency for the subwoofer output. This value can be
adjusted from 30 to 200 Hz.
The PHONS/CTRL R control adjusts the headphone or
control room volume (see also
).
PMP3000/PMP5000: The MAIN 2 control determines the
volume at the MAIN 2 output (see also
), which is the
same signal as at MAIN 1, but with extra output jacks and
separate volume control.
PMP3000/PMP5000: With the CD/TAPE IN control you can
adjust the volume of the line signal present at the CD/TAPE
INPUT
. Use the PFL switch to monitor the signal.
PMP1000: With the CD/TAPE RET fader you can adjust
the line signal applied to the CD/TAPE INPUT
. Use the
CD/TAPE MUTE switch to mute the channel.
