EURODESK SL3242FX-PRO/SL2442FX-PRO
1. INTRODUCTION
Congratulations! With the EURODESK you have acquired a
state-of-the-art mixing console that sets new standards. Right
from the very start it has been our goal to design a revolutionary
unit that can be used for a great variety of applications. And
indeed, this overwhelming mixing console gives you plenty of
functionality and a broad range of connection and expansion
options.
BEHRINGER is a company with its roots in professional
recording studio technology. For many years now we have
been successful in developing products for studio and live use.
These include microphones and studio gear of all kinds
(compressors, enhancers, noise gates, tube processors,
headphone amplifiers, digital effects, DI boxes, etc.), monitor
and P.A. speakers as well as professional live and recording
mixers. Our entire technical know-how has gone into your
EURODESK mixing console.
FBQ Feedback Detection System
One of the most outstanding features of this console
is the FBQ Feedback Detection System, which is
part of the graphic equalizer. This ingenious circuit
makes it possible to detect and subsequently
eliminate feedback frequencies very quickly. FBQ
increases the brightness of the EQ fader LEDs for the frequency
bands where feedback is occurring. What used to be a tedious
search for feedback frequencies is now mere childs play.
IMP Invisible Mic Preamp
The microphone channels are equipped with
BEHRINGERs brand-new high-end IMP Invisible
Mic Preamps, which offer you:
s 130 dB of dynamic range and hence an unbelievable amount
of headroom,
s a bandwidth from below 10 Hz to above 200 kHz for the
crystal-clear reproduction of even the slightest details,
s extremely noise and distortion-free circuitry for absolutely
natural sound and neutral signal reproduction,
s perfect adaptation to any microphone on the market (up
to 60 dB gain and +48 V phantom power), and
s the possibility of pushing the dynamic range of your
24-bit/192-kHz HD recorder to the max and thus achieving
ultimate audio quality.
What is more, the EURODESK comes with two effects
processors using 24-bit A/D and D/A converters and
the effects algorithms of our renowned 19" multi-
effects device VIRTUALIZER PRO DSP2024P. Each
processor offers 99 presets with first-class room simulations,
delay and modulation effects as well as compressor, tube
distortion and numerous other effects availableall with excellent
audio quality!
The mixer is equipped with a state-of-the-art
integrated switch-mode power supply. Unlike
conventional designs, this supply automatically
adapts to supply voltages between 100 and
240 V. With its considerably higher efficiency, it is
also more economical in terms of power consumption than
standard power supply units.
1. INTRODUCTION
1.1 Before you get started
1.1.1 Shipment
Your EURODESK was carefully packed at the factory and the
packaging is designed to protect the unit from rough handling.
We still recommend that you carefully examine the packaging
and its contents for any signs of physical damage that may have
occurred during transit.
+ If the unit is damaged, please do NOT return it to
BEHRINGER, but notify your dealer and the shipping
company immediately. Otherwise, claims for damage
or replacement may not be granted.
+ We recommend that you use a flight case, so as to
give your mixer optimum protection during use or
transport.
+ Always use the original packing carton to prevent
damage during storage or transport.
+ Make sure that children cannot play unsupervised with
the device or its packaging.
+ Please ensure proper disposal of all packing materials.
1.1.2 Initial operation
Be sure that there is enough air space around the unit for
cooling and, to avoid overheating, please do not place the
EURODESK near radiators, etc.
+ Blown fuses must be replaced by fuses of the same type
and rating! Please refer to the SPECIFICATIONS for
details.
The mains connection is made using the enclosed power cord
and a standard IEC receptacle. It meets all of the international
safety certification requirements.
+ Please make sure that all units have a proper ground
connection. For your own safety, never remove or
disable the ground conductor from the unit or on the
AC power cord.
1.1.3 Warranty
The EURODESKs serial number is located on the rear panel.
Please take the time to fill in and return the warranty card within
14 days after the date of purchase, so as to benefit from our
extended warranty. Or register online at www.behringer.com.
1.2 The manual
This manual is designed to give you an overview of all control
elements and at the same time inform you in detail about how to
use them. To provide you with a clear structure, we have grouped
the control elements according to their function. They can easily
be found on the enclosed numbered illustrations. If you need
more detailed information on specific topics, please visit our
web site at www.behringer.com. The product-related information
pages and the ULTRANET-based glossary explain the relevant
audio engineering terminology in full detail.
