V32 GUITAR AMPLIFIER
V32 TECHNICAL SPECIFICATIONS:
OUTPUT POWER RATING 30Watts RMS @ 6 % THD, 8 ohm load, 120VAC
SIGNAL TO NOISE RATIO 71dB Typical
GAIN Clean 56dB, Overdrive 101dB
TREBLE 12dB range @ 6kHz
BOOST +10dB @ 900Hz
MID 10dB range @ 1kHz
BASS 8dB range @ 150Hz
PRESENCE +8dB @ 10kHz
INTERNAL SPEAKER 12”, 80W Celestion, 8 ohm, 1.75” voice coil dia, 30oz magnet
PREAMP TUBES (3) 12AX7A
POWER AMP TUBES (4) EL84
POWER REQUIREMENTS 120VAC, 60 Hz, 35VA
100/115 VAC, 50/60Hz, 35VA
230 VAC, 50/60Hz, 35VA
SIZE AND WEIGHT 21” H x 17-1/2” W x 10” D, 44 lbs.
The V32 is covered with a durable Tolex material: wipe it clean with a lint-free cloth.
Never spray cleaning agents onto the cabinet. Avoid abrasive cleansers which would damage the finish.
Specifications and information in this manual are subject to change without notice.
www.crateamps.com
@2005 SLM Electronics, a division of St. Louis Music, Inc • 1400 Ferguson Avenue • St. Louis, MO 63133
47-461-03 • 011805
