5
15. AC Line Cord: The grounded power cord
should only be plugged into a grounded power
outlet that meets all applicable electrical codes
and is compatible with the voltage, power, and
frequency requirements stated on the rear
panel. Do not attempt to defeat the safety
ground connection.
16. Line Out: Use this 1/4” jack to send a line
level signal to a mixing board, external power
amplifier or powered monitor, or to the input
jack of an external signal processor.
17. Line In: Use this 1/4” jack to connect the
output of an external effects processor to the
amplifier.
18. 8 Ohm Speaker: The V32 is shipped with
a cable connected from this jack to the internal
speaker. To connect the amplifier to an external
speaker cabinet, disconnect the cable from the
amplifier and use the jack to connect the exter-
nal cabinet to the amplifier by means of a
heavy duty Class 2 wiring speaker cable termi-
nated with 1/4” plugs. The total impedance rat-
ing for the external speaker(s) must be 8 ohms.
19. Footswitch: Use this jack to connect the
supplied two-button footswitch for remote control
of channel switching and the Boost function. The
front panel Clean/Overdrive and Boost switches
(#3, #6) are inoperative when a footswitch is con-
nected.
The Rear Panel (not shown):
V32 GUITAR AMPLIFIER
