NUMBER THIRTEEN - TRANSMISSION COVER ASSEMBLY
Model 987070, 071, 072
Item Part No. Qty. Description
1 05960000 4 Bolt-Hex .50-13X3.25 Grade 5
2 051096 1 Seal 1.25 x 2.25 x .50
3 018812 1 Ring-Retaining-External 2.49 x .078
4 050473 1 Bearing-Ball 1.25 x 2.25 x .50 Sealed
5 046061 1 Axle Bearing Retainer
6 018030 1 Gasket
7 050117 1 Assembly, Transmission Cover
8 070238 1 Plug-Pipe .38 Suare Head Unfinished Steel
9 05963300 2 Bolt-Hex .38-16 x 2.00 Grade 5
10 018089 2 Pin-Dowel .38 x .63
11 05962900 2 Bolt-Hex .38-16 x 2.25 Grade 5
12 05957900 4 Bolt-Hex .38-16 x 1.50 Grade 5
PJ0190
1
2
3
4
5
6
7
8
9
10
11
12
