ELECTRICAL SYSTEM
Model 987070, 071, 072
Item Part No. Qty. Description
9 06529700 5 Nut-Locking-Center .25-20
10 05946800 5 Bolt-Hex .25-20 x .75 Grade 5
11 027122 2/1 Clamp
12 06529600 1 Nut-Locking-Center .38-16
13 042289 1 Connector
14 039862 1 Cable, Starter (071, 072) (S/N Range 000101 - 000214)
049032 1 Cable, Starter (071, 072) (S/N Range 000215 and up)
040135 1 Cable, Starter (070)
15 06535500 1 Nut-Locking-Center .38-16
16 011676 2 Nut-Speed .25-20
17 044766 1 Solenoid
18 033847 3 Boot, Insulator
19 045920 1 Assembly, Connector Weather Tight
20 045922 2 Terminal For 14-16 Gauge Wire
21 045037 1 Fuse, 25 AMP
22 045921 1 Cover
23 050673 1 Light, Indicator
24 021848 1 Gauge, Ammeter
25 046060 1 Switch, Light
26 045842 1 Key Chain
27 02460700 1 Key With Cap
28 045490 1 Cap, Ignition Switch
29 045489 1 Nut-Panel .56-24 (071, 072)
045497 1 Nut-Panel .625-32 (070)
30 06310900 1 Washer-Locking-Internal .56 x .040 (071, 072)
06301900 1 Washer-Locking-Internal .63 x .045 (070)
31 039871 1 Cable, Negative Battery (070)
04901600 1 Cable, Negative Battery (071, 072)
32 05946900 3 Bolt-Hex .31-18 x 1.00 Grade 5
33 06437200 6 Washer-Flat-Steel .34 x .69 x .065
34 06529800 3 Nut-Locking-Center .31-18
35 050395 1 Clamp-Steel 1.00
36 038256 1 Hour Meter
37 03602300 1 Switch, Key (071, 072)
08883300 1 Switch,Key (070)
38 038058 2 Connector
39 04901800 1 Harness, Wiring (071, 072)
08789200 1 Harness, Wiring (070)
40 09044200 1 Module, Interlock Delay
41 03042800 1 Relay
42 06437300 5 Washer-Flat-Steel 28 x .62 x .065
43 08745500 1 Cable, Battery To Magneto Switch
44 08779600 1 Harness, Wiring Ground and Lights
45 036313 6 Cable Tie
46 09044100 2 Adapter, Module
47 039069 2 Head Light
48 04202200 1 Battery
49 037742 2 Clamp
50 06220000 2 Bolt-Round Head Square Neck .25-20 x 1.75 Grade 5
51 06116900 2 Screw-Machine 10-24 x .75 Hex Washer Head
52 07027700 2 Nut-Retaining Ring 10-24
