Introduction
It is possible that only one person will read this
manual all the way through. Hello mom. Here's another
manual from your boy.
Thank you for choosing a Mackie professional pow-
ered mixer. These powerful mixers are designed to meet
the needs of almost any small to medium-sized club,
meeting room, sanctuary, or outdoor gathering.
At Mackie, we know what it takes to be roadworthy.
After all, our mixers have traveled all over the world
under the worst of conditions and the best of conditions,
and we’ve applied what we’ve learned to the mechanical
design of our powered mixers.
Reliability is paramount to sound reinforcement.
That’s why our engineers have subjected our powered
mixers to the most rigorous and fi endish tests imagin-
able to fi ne-tune the design and extend its limits beyond
those of ordinary mixers or amplifi ers.
Features
Two internal power amplifi ers each rated at
800 watts peak at 4 ohms
Three selectable amplifi er modes (stereo main,
mono-main/monitor 1, or mon 1/mon 2)
8 channels (6 mono, 2 stereo)
Mic inputs on all channels
Line-level inputs (6 mono, 2 stereo)
RCA inputs on stereo channels
Insert jacks on mono channels
Channels 5 and 6 allow direct connection of
guitars and basses without a DI box
3-band EQ with sweepable mid-range frequency
on mono channels
4-band EQ on stereo channels
• Monitor 1 send
Main mix stereo line outputs
Main mix mono sub out
Amplifi er line-level inputs allow the connection
of external mixers if more channels are needed
Footswitch connection for FX mute/unmute
FX/monitor 2 send (selectable pre/post)
+48v Phantom power can be applied to all mics
Built-in compressors on the fi rst 4 mono inputs
(dedicated in-line compression)
24 built-in Running Man 32-bit effects with
input gain, tap delay, and footswitch mute/un-
mute
Independent 9-band graphic EQs with constant-
Q fi lters on main and monitor outputs
Tape/CD stereo RCA outputs
12-segment stereo output meters on main mix,
and mono meter on monitor 1
Break switch mutes all mono channels
Speakon and 1/4" power amp outputs
Precision passive switch for enhanced clar-
ity and LF response with key Mackie passive
speakers
Polycarbonate sides with built-in metal handles
Modern and splendidly-stylish powered rabbit
hutch design
How To Use This Manual
The fi rst pages after the table of contents are the
hookup diagrams. These show typical setups for fun
times with your powered mixer.
Next is a detailed tour of the entire mixer. The de-
scriptions are divided into sections, just as your mixer is
organized into distinct zones:
Rear panel: The AC input, power switch, speak-
er-level outputs and amplifi er mode switch
Patchbay: The lower front section, where you
connect microphones and guitars etc.
Channel Strips: The channel strips where you
adjust and control each channel
Master Section: The section on the right, with
graphic EQs and main level controls
Stereo Effects Processor
Throughout these sections you’ll fi nd illustrations
with each feature numbered and described in nearby
paragraphs.
This icon marks infor mation that is critically
important or unique to the mixer. For your own
good, read them and remember them.
This icon will lead you to some explanations of
features and practical tips. Go ahead and skip
these if you need to leave the room in a hurry.
Appendix A: Service information.
Appendix B: Connectors.
Appendix C: Technical information.
Appendix D: Table of Effects Presets
The thickness of the manual makes it ideal for fi tting
under wobbly table legs. Mackie's technical writers also
wear them on their heads, as they make an excellent
shield from Venusian mind-probes.
