E 20
ENGLISH
RADIO TUNER OPERATION
Listening to Radio
1. Press function button, or RADIO/BAND button on the remote control to select radio mode.
2. Press BAND AM/FM button, or RADIO/BAND button on the remote control to select FM or AM
band.
3. Press TUNING +/- to select a radio station.
Note:
• Short press TUNING + or TUNING -, the receiving frequency step moves up or down
incrementally.
• If you press and hold TUNING + or TUNING - for more than few seconds, the frequency
will continue to increase or decrease automatically until a radio station is received.
• The last tuned station is retained and recalled when you turn the system on. The tuned
station is stored into memory even if power is disconnected or cut due to temporary power
failure.
Setting Radio Stations into Memory
You may store up to 20 FM stations and 20 AM stations in channel memory.
1. Press BAND AM/FM button to select FM or AM band.
2. Press TUNING + or TUNING - to select a radio station.
3. Press PROGRAM button to enter saving mode.
4. Press PRESET +/- button to select preset channel.
5. Press PROGRAM button to save into memory. If it has been previously set, the
former station is replaced.
6. Repeat step 2 to 5 to store additional stations.
Playing Preset Stations
1. Press BAND AM/FM button to select FM or AM band.
2. Press PRESET +/- to select the desired preset channel.
Improving Reception
AM Reception
• Plug in the external AM antenna loop at the back of unit. (#23 note on. the control locations on
page E5.)
• The AM loop antenna should be placed up to 12” away from the unit for best reception.
Rotate the AM loop antenna as required for best AM reception.
• Do not put the other electronic adapter close to the system or antenna, this may increase
noise and influence the AM broadcasting station.
FM Reception
• Fully unwind the FM wire antenna and position it for best FM signal reception.
