This unit includes 215 high quality percussion sounds, which you can
assign to any of the drum pads, 3 cymbals, hi-hat control and bass
drum. This allows you to create your own drum kit, which consists of
the voice you choose. Reference voice list: page E13.
The kit number 021-030 are used for saving your own drum kit.
1.Press[voice]button.
The voice indicator illuminates and displays the number of the pad.
2. Press [ pad ] button or hit the pad you want to set. The pad
indicator will illuminate and display the current voice number of the
lit pad.
3.Press[+]or[-]buttonstoselectthevoice number you want to
assign.
4. Repeat step 2 and 3 to set the voice for another pad or bass drum.
All settings will be reset to default once power is ON.
*
This unit allows you to adjust the volume of every voice in the kit and
also will control the individual level (volume) of the pads or bass drum.
1. Press the [ voice / volume ] button to view the volume level setting.
Level settings run from 00 to 31 The pad button indicator
illuminates and will display the current volume level of the lit pad.
2. Press the [ PAD ] button or kit the percussion pad you want to
adjust.
3.Pressthe[+]or[-]toincreaseordecreasethevolume. While
you are adjusting the corresponding pad, listen carefully to the
sound level until reaching the level you desire.
4. Repeat step 2 and 3 to adjust the volume of other pad voices.
Volume of the pad will be reset to default once power is ON.
*
Upon completion of your personalized drum kits please follow the steps
below to save them:
1.Press[save]button.
The kit number 021 appears and is flashing.
2.Press[+]or[-]buttontosetthekitnumber(021-030) for saving
your drum kit.
3. Press [ save ] button again. The flashing kit number stops.
Note: To cancel the save operation, press the voice button. If
there is an error “Err” will be displayed.
English
E11
CREATE A USER DRUM KIT
Save your drum kit voices
Set a Drum voice
Adjust the volume of the Pad
Voice indicator
Pad buttons
Volume level value
Pad indicator
