122
HALL, ROOM, STAGE, PLATE
No. Parameter Value See Table Control
1 Reverb Time 0.3~30.0s 0-69 table#4
2 Diffusion 0~10 0-10
3 Initial Delay 0.1ms~99.3ms 0-63 table#5
4 HPF Cutoff Thru~8.0kHz 0-52 table#3
5 LPF Cutoff 1.0k~Thru 34-60 table#3
6
7
8
9
10 Dry/Wet D63>W ~ D=W ~ D<W63 1-127
11 Rev Delay 0.1ms~99.3ms 0-63 table#5
12 Density 0~4 (reverb, variation block) 0-4
0~2 (insertion block) 0-2
13 Er/Rev Balance E63>R ~ E=R ~ E<R63 1-127
14 High Damp 0.1~1.0 1-10
15 Feedback Level -63~+63 1-127
16
WHITE ROOM, TUNNEL, CANYON, BASEMENT (reverb, variation block)
No. Parameter Value See Table Control
1 Reverb Time 0.3~30.0s 0-69 table#4
2 Diffusion 0~10 0-10
3 Initial Delay 0.1ms~99.3ms 0-63 table#5
4 HPF Cutoff Thru~8.0kHz 0-52 table#3
5 LPF Cutoff 1.0k~Thru 34-60 table#3
6 Width 0.5~10.2m 0-37 table#11
7 Heigt 0.5~20.2m 0-73 table#11
8 Depth 0.5~30.2m 0-104 table#11
9 Wall Vary 0~30 0-30
10 Dry/Wet D63>W ~ D=W ~ D<W63 1-127
11 Rev Delay 0.1ms~99.3ms 0-63 table#5
12 Density 0~4 0-4
13 Er/Rev Balance E63>R ~ E=R ~ E<R63 1-127
14 High Damp 0.1~1.0 1-10
15 Feedback Level -63~+63 1-127
16
DELAY L,C,R (variation, insertion block)
No. Parameter Value See Table Control
1 Lch Delay 0.1~1486.0ms (variation block) 1-14860
0.1~742.9ms (insertion block) 1-7429
2 Rch Delay 0.1~1486.0ms (variation block) 1-14860
0.1~742.9ms (insertion block) 1-7429
3 Cch Delay 0.1~1486.0ms (variation block) 1-14860
0.1~742.9ms (insertion block) 1-7429
4 Feedback Delay 0.1~1486.0ms (variation block) 1-14860
0.1~742.9ms (insertion block) 1-7429
5 Feedback Level -63~+63 1-127
6 Cch Level 0~127 0-127
7 High Damp 0.1~1.0 1-10
8
9
10 Dry/Wet D63>W ~ D=W ~ D<W63 1-127
11
12
13 EQ Low Frequency 32Hz~2.0kHz 4-40 table#3
14 EQ Low Gain -12~+12dB 52-76
15 EQ High Frequency 500Hz~16.0kHz 28-58 table#3
16 EQ High Gain -12~+12dB 52-76
DELAY L,R (variation, insertion block)
No. Parameter Value See Table Control
1 Lch Delay 0.1~1486.0ms (variation block) 1-14860
0.1~742.9ms (insertion block) 1-7429
2 Rch Delay 0.1~1486.0ms (variation block) 1-14860
0.1~742.9ms (insertion block) 1-7429
3 Feedback Delay 1 0.1~1486.0ms (variation block) 1-14860
0.1~742.9ms (insertion block) 1-7429
4 Feedback Delay 2 0.1~1486.0ms (variation block) 1-14860
0.1~742.9ms (insertion block) 1-7429
5 Feedback Level -63~+63 1-127
6 High Damp 0.1~1.0 1-10
7
8
9
10 Dry/Wet D63>W ~ D=W ~ D<W63 1-127
11
12
13 EQ Low Frequency 32Hz~2.0kHz 4-40 table#3
14 EQ Low Gain -12~+12dB 52-76
15 EQ High Frequency 500Hz~16.0kHz 28-58 table#3
16 EQ High Gain -12~+12dB 52-76
ECHO (variation, insertion block)
No. Parameter Value See Table Control
1 Lch Delay1 0.1~743.0ms (variation block) 1-7430
0.1~371.4ms (insertion block) 1-3714
2 Lch Feedback Level -63~+63 1-127
3 Rch Delay1 0.1~743.0ms (variation block) 1-7430
0.1~371.4ms (insertion block) 1-3714
4 Rch Feedback Level -63~+63 1-127
5 High Damp 0.1~1.0 1-10
6 Lch Delay2 0.1~743.0ms (variation block) 1-7430
0.1~371.4ms (insertion block) 1-3714
7 Rch Delay2 0.1~743.0ms (variation block) 1-7430
0.1~371.4ms (insertion block) 1-3714
8 Delay2 Level 0~127 0-127
9
10 Dry/Wet D63>W ~ D=W ~ D<W63 1-127
11
12
13 EQ Low Frequency 32Hz~2.0kHz 4-40 table#3
14 EQ Low Gain -12~+12dB 52-76
15 EQ High Frequency 500Hz~16.0kHz 28-58 table#3
16 EQ High Gain -12~+12dB 52-76
CROSS DELAY (variation, insertion block)
No. Parameter Value See Table Control
1 L->R Delay 0.1~743.0ms (variation block) 1-7430
0.1~371.4ms (insertion block) 1-3714
2 R->L Delay 0.1~743.0ms (variation block) 1-7430
0.1~371.4ms (insertion block) 1-3714
3 Feedback Level -63~+63 1-127
4 Input Select L,R,L&R 0-2
5 High Damp 0.1~1.0 1-10
6
7
8
9
10 Dry/Wet D63>W ~ D=W ~ D<W63 1-127
11
12
13 EQ Low Frequency 32Hz~2.0kHz 4-40 table#3
14 EQ Low Gain -12~+12dB 52-76
15 EQ High Frequency 500Hz~16.0kHz 28-58 table#3
16 EQ High Gain -12~+12dB 52-76
EARLY REF (variation block)
No. Parameter Value See Table Control
1 Type S-H, L-H, Rdm, Rvs, Plt, Spr 0-5
2 Room Size 0.1~7.0 0-44 table#6
3 Diffusion 0~10 0-10
4 Initial Delay 0.1ms~99.3ms 0-63 table#5
5 Feedback Level -63~+63 1-127
6 HPF Cutoff Thru~8.0kHz 0-52 table#3
7 LPF Cutoff 1.0k~Thru 34-60 table#3
8
9
10 Dry/Wet D63>W ~ D=W ~ D<W63 1-127
11 Liveness 0~10 0-10
12 Density 0~3 0-3
13 High Damp 0.1~1.0 1-10
14
15
16
GATE REVERB, REVERSE GATE (variation block)
No. Parameter Value See Table Control
1 Type TypeA,TypeB 0-1
2 Room Size 0.1~20.0 0-127 table#6
3 Diffusion 0~10 0-10
4 Initial Delay 0.1ms~200ms 0-127 table#5
5 Feedback Level -63~+63 1-127
6 HPF Cutoff Thru~8.0kHz 0-52 table#3
7 LPF Cutoff 1.0k~Thru 34-60 table#3
8
9
10 Dry/Wet D63>W ~ D=W ~ D<W63 1-127
11 Liveness 0~10 0-10
12 Density 0~3 0-3
13 High Damp 0.1~1.0 1-10
14
15
16
KARAOKE (variation, insertion block)
No. Parameter Value See Table Control
1 Delay Time 0.1ms~400ms 0-127 table#7
2 Feedback Level -63~+63 1-127
3 HPF Cutoff Thru~8.0kHz 0-52 table#3
4 LPF Cutoff 1.0k~Thru 34-60 table#3
5
6
7
8
9
10 Dry/Wet D63>W ~ D=W ~ D<W63 1-127
11
12
13
14
15
16
CHORUS, CELESTE (chorus, variation, insertion block)
No. Parameter Value See Table Control
1 LFO Frequency 0.00Hz~39.7Hz 0-127 table#1
2 LFO Depth 0~127 0-127
3 Feedback Level -63~+63 1-127
4 Delay Offset 0~127 0-127 table#2
5
6 EQ Low Frequency 32Hz~2.0kHz 4-40 table#3
7 EQ Low Gain -12~+12dB 52-76
8 EQ High Frequency 500Hz~16.0kHz 28-58 table#3
9 EQ High Gain -12~+12dB 52-76
10 Dry/Wet D63>W ~ D=W ~ D<W63 1-127
11 EQ Mid Frequency 100Hz~10.0kHz (variation block) 14-54 table#3
12 EQ Mid Gain -12~+12dB (variation block) 52-76
13 EQ Mid Width 1.0~12.0 (variation block) 10-120
14
15 Input Mode mono/stereo 0-1
16
FLANGER (chorus, variation, insertion block)
No. Parameter Value See Table Control
1 LFO Frequency 0.00Hz~39.7Hz 0-127 table#1
2 LFO Depth 0~127 0-127
3 Feedback Level -63~+63 1-127
4 Delay Offset 0~127 0-127 table#2
5
6 EQ Low Frequency 32Hz~2.0kHz 4-40 table#3
7 EQ Low Gain -12~+12dB 52-76
8 EQ High Frequency 500Hz~16.0kHz 28-58 table#3
9 EQ High Gain -12~+12dB 52-76
10 Dry/Wet D63>W ~ D=W ~ D<W63 1-127
11 EQ Mid Frequency 100Hz~10.0kHz (variation block) 14-54 table#3
12 EQ Mid Gain -12~+12dB (variation block) 52-76
13 EQ Mid Width 1.0~12.0 (variation block) 10-120
14
LFO Phase Difference
-180~+180deg(resolution=3deg.) 4-124
15
16
