124
3BAND EQ(MONO) (variation, insertion block)
No. Parameter Value See Table Control
1 EQ Low Gain -12~+12dB 52-76
2 EQ Mid Frequency 100Hz~10.0kHz 14-54 table#3
3 EQ Mid Gain -12~+12dB 52-76
4 EQ Mid Width 1.0~12.0 10-120
5 EQ High Gain -12~+12dB 52-76
6 EQ Low Frequency 50Hz~2.0kHz 8-40 table#3
7 EQ High Frequency 500Hz~16.0kHz 28-58 table#3
8
9
10
11
12
13
14
15 Input Mode mono/stereo 0-1
16
AMP SIMULATOR (variation, insertion block)
No. Parameter Value See Table Control
1 Drive 0~127 0-127
2 AMP Type Off,Stack,Combo,Tube 0-3
3 LPF Cutoff 1.0k~Thru 34-60 table#3
4 Output Level 0~127 0-127
5
6
7
8
9
10 Dry/Wet D63>W ~ D=W ~ D<W63 1-127
11 Edge(Clip Curve) 0~127 0-127 mild~sharp
12
13
14
15
16
2BAND EQ(STEREO) (variation, insertion block)
No. Parameter Value See Table Control
1 EQ Low Frequency 32Hz~2.0kHz 4-40 table#3
2 EQ Low Gain -12~+12dB 52-76
3 EQ High Frequency 500Hz~16.0kHz 28-58 table#3
4 EQ High Gain -12~+12dB 52-76
5
6
7
8
9
10
11
12
13
14
15
16
AUTO WAH (variation, insertion block)
No. Parameter Value See Table Control
1 LFO Frequency 0.00Hz~39.7Hz 0-127 table#1
2 LFO Depth 0~127 0-127
3
Cutoff Frequency Offset
0~127 0-127
4 Resonance 1.0~12.0 10-120
5
6 EQ Low Frequency 32Hz~2.0kHz 4-40 table#3
7 EQ Low Gain -12~+12dB 52-76
8 EQ High Frequency 500Hz~16.0kHz 28-58 table#3
9 EQ High Gain -12~+12dB 52-76
10 Dry/Wet D63>W ~ D=W ~ D<W63 1-127
11 Drive 0~127 0-127
12
13
14
15
16
AUTO WAH+DIST, AUTO WHA+ODRV (variation block)
No. Parameter Value See Table Control
1 LFO Frequency 0.00Hz~39.7Hz 0-127 table#1
2 LFO Depth 0~127 0-127
3
Cutoff Frequency Offset
0~127 0-127
4 Resonance 1.0~12.0 10-120
5
6 EQ Low Frequency 32Hz~2.0kHz 4-40 table#3
7 EQ Low Gain -12~+12dB 52-76
8 EQ High Frequency 500Hz~16.0kHz 28-58 table#3
9 EQ High Gain -12~+12dB 52-76
10 Dry/Wet D63>W ~ D=W ~ D<W63 1-127
11 Drive 0~127 0-127
12
EQ Low Gain(distortion)
-12~+12dB 52-76
13
EQ Mid Gain(distortion)
-12~+12dB 52-76
14 LPF Cutoff 1.0kHz~thru 34-60 table#3
15 Output Level 0~127 0-127
16
TOUCH WAH 1 (variation, insertion block), TOUCH WAH+DIST (variation block)
No. Parameter Value See Table Control
1 Sensitive 0~127 0-127
2
Cutoff Frequency Offset
0~127 0-127
3 Resonance 1.0~12.0 10-120
4
5
6 EQ Low Frequency 32Hz~2.0kHz 4-40 table#3
7 EQ Low Gain -12~+12dB 52-76
8 EQ High Frequency 500Hz~16.0kHz 28-58 table#3
9 EQ High Gain -12~+12dB 52-76
10 Dry/Wet D63>W ~ D=W ~ D<W63 1-127
11 Drive 0~127 0-127
12
13
14
15
16
TOUCH WAH 2 (variation, insertion block), TOUCH WAH+ODRV (variation block)
No. Parameter Value See Table Control
1 Sensitive 0~127 0-127
2
Cutoff Frequency Offset
0~127 0-127
3 Resonance 1.0~12.0 10-120
4
5
6 EQ Low Frequency 32Hz~2.0kHz 4-40 table#3
7 EQ Low Gain -12~+12dB 52-76
8 EQ High Frequency 500Hz~16.0kHz 28-58 table#3
9 EQ High Gain -12~+12dB 52-76
10 Dry/Wet D63>W ~ D=W ~ D<W63 1-127
11 Drive 0~127 0-127
12
EQ Low Gain(distortion)
-12~+12dB 52-76
13
EQ Mid Gain(distortion)
-12~+12dB 52-76
14 LPF Cutoff 1.0kHz~thru 34-60 table#3
15 Output Level 0~127 0-127
16
PITCH CHANGE 1 (variation block)
No. Parameter Value See Table Control
1 Pitch -24~+24 40-88
2 Initial Delay 0.1ms~400ms 0-127 table#7
3 Fine 1 -50Hz~+50Hz 14-114
4 Fine 2 -50Hz~+50Hz 14-114
5 Feedback Level -99~+99% 1-127
6
7
8
9
10 Dry/Wet D63>W ~ D=W ~ D<W63 1-127
11 Pan 1 L63~R63 1-127
12 Output Level 1 0~127 0-127
13 Pan 2 L63~R63 1-127
14 Output Level 2 0~127 0-127
15
16
COMPRESSOR (variation, insertion block)
No. Parameter Value See Table Control
1 Attack 1~40ms 0-19 table#8
2 Release 10~680ms 0-15 table#9
3 Threshold -48~-6dB 79-121
4 Ratio 1.0~20.0 0-7 table#10
5 Output Level 0~127 0-127
6
7
8
9
10
11
12
13
14
15
16
NOISE GATE (variation, insertion block)
No. Parameter Value See Table Control
1 Attack 1~40ms 0-19 table#8
2 Release 10~680ms 0-15 table#9
3 Threshold -72~-30dB 55-97
4 Output Level 0~127 0-127
5
6
7
8
9
10
11
12
13
14
15
16
PITCH CHANGE 2 (variation block)
No. Parameter Value See Table Control
1 Pitch -24~+24 40-88
2 Initial Delay 0.1ms~400ms 0-127 table#7
3 Fine 1 -50~+50cent 14-114
4 Fine 2 -50~+50cent 14-114
5 Feedback Level -99~+99% 1-127
6
7
8
9
10 Dry/Wet D63>W ~ D=W ~ D<W63 1-127
11 Pan 1 L63~R63 1-127
12 Output Level 1 0~127 0-127
13 Pan 2 L63~R63 1-127
14 Output Level 2 0~127 0-127
15
16
