PHASER 1 (chorus, variation, insertion block)
No. Parameter Value See Table Control
1 LFO Frequency 0.00Hz~39.7Hz 0-127 table#1
2 LFO Depth 0~127 0-127
3 Phase Shift Offset 0~127 0-127
4 Feedback Level -63~+63 1-127
5
6 EQ Low Frequency 32Hz~2.0kHz 4-40 table#3
7 EQ Low Gain -12~+12dB 52-76
8 EQ High Frequency 500Hz~16.0kHz 28-58 table#3
9 EQ High Gain -12~+12dB 52-76
10 Dry/Wet D63>W ~ D=W ~ D<W63 1-127
11 Stage 4,5,6 (chorus, insertion block) 4-6
4~12 (variation block) 4-12
12 Diffusion mono/stereo 0-1
13
14
15
16
PHASER 2 (variation block)
No. Parameter Value See Table Control
1 LFO Frequency 0.00Hz~39.7Hz 0-127 table#1
2 LFO Depth 0~127 0-127
3 Phase Shift Offset 0~127 0-127
4 Feedback Level -63~+63 1-127
5
6 EQ Low Frequency 32Hz~2.0kHz 4-40 table#3
7 EQ Low Gain -12~+12dB 52-76
8 EQ High Frequency 500Hz~16.0kHz 28-58 table#3
9 EQ High Gain -12~+12dB 52-76
10 Dry/Wet D63>W ~ D=W ~ D<W63 1-127
11 Stage 3,4,5,6 3-6
12
13
LFO Phase Difference
-180deg~+180deg(resolution=3deg.)
4-124
14
15
16
DISTORTION, OVERDRIVE (variation, insertion block)
No. Parameter Value See Table Control
1 Drive 0~127 0-127
2 EQ Low Frequency 32Hz~2.0kHz 4-40 table#3
3 EQ Low Gain -12~+12dB 52-76
4 LPF Cutoff 1.0k~Thru 34-60 table#3
5 Output Level 0~127 0-127
6
7 EQ Mid Frequency 100Hz~10.0kHz 14-54 table#3
8 EQ Mid Gain -12~+12dB 52-76
9 EQ Mid Width 1.0~12.0 10-120
10 Dry/Wet D63>W ~ D=W ~ D<W63 1-127
11 Edge(Clip Curve) 0~127 0-127 mild~sharp
12
13
14
15
16
COMP+DIST (variation block)
No. Parameter Value See Table Control
1 Drive 0~127 0-127
2 EQ Low Frequency 32Hz~2.0kHz 4-40 table#3
3 EQ Low Gain -12~+12dB 52-76
4 LPF Cutoff 1.0k~Thru 34-60 table#3
5 Output Level 0~127 0-127
6
7 EQ Mid Frequency 100Hz~10.0kHz 14-54 table#3
8 EQ Mid Gain -12~+12dB 52-76
9 EQ Mid Width 1.0~12.0 10-120
10 Dry/Wet D63>W ~ D=W ~ D<W63 1-127
11 Edge(Clip Curve) 0~127 0-127 mild~sharp
12 Attack 1ms~40ms 0-19 table#8
13 Release 10ms~680ms 0-15 table#9
14 Threshold -48dB~-6dB 79-121
15 Ratio 1.0~20.0 0-7 table#10
TREMOLO (variation, insertion block)
No. Parameter Value See Table Control
1 LFO Frequency 0.00Hz~39.7Hz 0-127 table#1
2 AM Depth 0~127 0-127
3 PM Depth 0~127 0-127
Input Mode mono/stereo 0-1
4
5
6 EQ Low Frequency 32Hz~2.0kHz 4-40 table#3
7 EQ Low Gain -12~+12dB 52-76
8 EQ High Frequency 500Hz~16.0kHz 28-58 table#3
9 EQ High Gain -12~+12dB 52-76
10
11 EQ Mid Frequency 100Hz~10.0kHz (variation block) 14-54 table#3
12 EQ Mid Gain -12~+12dB (variation block) 52-76
13 EQ Mid Width 1.0~12.0 (variation block) 10-120
14
LFO Phase Difference
-180~+180deg(resolution=3deg.) 4-124
15
16
AUTO PAN (variation, insertion block)
No. Parameter Value See Table Control
1 LFO Frequency 0.00Hz~39.7Hz 0-127 table#1
2 L/R Depth 0~127 0-127
3
F/R Depth 0~127 0-127
4
5
6 EQ Low Frequency 32Hz~2.0kHz 4-40 table#3
7 EQ Low Gain -12~+12dB 52-76
8 EQ High Frequency 500Hz~16.0kHz 28-58 table#3
9 EQ High Gain -12~+12dB 52-76
10
PAN Direction
L<->R, L->R, L<-R, Lturn, Rturn, L/R
0-5
11 EQ Mid Frequency 100Hz~10.0kHz (variation block) 14-54 table#3
12 EQ Mid Gain -12~+12dB (variation block) 52-76
13 EQ Mid Width 1.0~12.0 (variation block) 10-120
14
15
16
SYMPHONIC (chorus, variation, insertion block)
No. Parameter Value See Table Control
1 LFO Frequency 0.00Hz~39.7Hz 0-127 table#1
2 LFO Depth 0~127 0-127
3 Delay Offset 0~127 0-127 table#2
4
5
6 EQ Low Frequency 32Hz~2.0kHz 4-40 table#3
7 EQ Low Gain -12~+12dB 52-76
8 EQ High Frequency 500Hz~16.0kHz 28-58 table#3
9 EQ High Gain -12~+12dB 52-76
10 Dry/Wet D63>W ~ D=W ~ D<W63 1-127
11 EQ Mid Frequency 100Hz~10.0kHz (variation block) 14-54 table#3
12 EQ Mid Gain -12~+12dB (variation block) 52-76
13 EQ Mid Width 1.0~12.0 (variation block) 10-120
EQ Mid Frequency 100Hz~10.0kHz (variation block) 14-54 table#3
EQ Mid Gain -12~+12dB (variation block) 52-76
EQ Mid Width 1.0~12.0 (variation block) 10-120
14
15
16
ENSEMBLE DETUNE (chorus, variation, insertion block)
No. Parameter Value See Table Control
1 Detune -50~+50cent 14-114
2 Lch Init Delay 0~127 0-127 table#2
table#2
table#3
table#3
3 Rch Init Delay 0~127 0-127
4
5
6
7
8
9
10 Dry/Wet D63>W ~ D=W ~ D<W63 1-127
Dry/Wet D63>W ~ D=W ~ D<W63 1-127
11 EQ Low Frequency
32Hz~2.0kHz (variation, insertion block)
4-40
12 EQ Low Gain
-12~+12dB 52-76 (variation, insertion block)
EQ High Gain
-12~+12dB (variation, insertion block)
52-76
13 EQ High Frequency
500Hz~16.0kHz (variation, insertion block)
28-58
table#3
table#3
EQ Low Frequency 32Hz~2.0kHz 4-40
EQ Low Gain -12~+12dB 52-76
EQ High Gain -12~+12dB 52-76
EQ High Frequency 500Hz~16.0kHz 28-58
Dry/Wet D63>W ~ D=W ~ D<W63 1-127
table#3
table#3
EQ Low Frequency 32Hz~2.0kHz 4-40
EQ Low Gain -12~+12dB 52-76
EQ High Gain -12~+12dB 52-76
EQ High Frequency 500Hz~16.0kHz 28-58
14
15
16
AMBIENCE (variation block)
No. Parameter Value See Table Control
1 Delay Time 0~127 0-127
2 Output Phase normal/invers 0-1
table#2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
ROTARY SPEAKER (variation, insertion block)
No. Parameter Value See Table Control
1 LFO Frequency 0.00Hz~39.7Hz 0-127 table#1
2 LFO Depth 0~127 0-127
3
4
5
6
7
8
9
10
11
12
13
14
15
16
2WAY ROTARY SPEAKER (variation block)
No. Parameter Value See Table Control
1 Rotor Speed 0.0Hz~39.7Hz 0-127 table#1
2 Drive Low 0~127 0-127
3 Drive High 0~127 0-127
4 Low/HIgh L63>H ~ L=H ~ L<H63 1-127
5
6 EQ Low Frequency 32Hz~2.0kHz 4-40 table#3
7 EQ Low Gain -12~+12dB 52-76
8 EQ High Frequency 500Hz~16.0kHz 28-58 table#3
9 EQ High Gain -12~+12dB 52-76
10
11
Crossover Frequency
100Hz~10.0kHz 14-54 table#3
12 Mic L-R Angle 0deg~180deg (resolution=3deg.) 0-60
13
14
15
16
