30 Touch Screen Display
MX6 User’s Guide E-EQ-MX6OGWW-E-ARC
Touch Screen Display
Figure 26 Tapping with the Stylus
The MX6 Touch Screen display is a color TFT VGA display with a user programmable backlight.
Display size is 320 x 240 pixels in portrait orientation. The display covering is designed to resist
stains. The touch screen allows signature capture and touch input. A pen stylus is included.
System Tray Icons
Turns system sounds on and
off and is used to adjust the
volume of system sounds.
Connection is active.
Backup battery is low.
Synchronization is beginning or ending.
Main batteries are charging.
Synchronization is occuring.
Main batteries are low.
One or more instant messages are
waiting acknowledgment.
Main batteries very low.
One or more e-mail messages are
waiting acknowledgment.
Main batteries are full.
Soft Input Panel. Tap to show the Panel.
Figure 27 System Tray Icons
