EURODESK SX4882
Specications 25
Specications24.
Main channel strip
Mic input
Type electronically balanced, discrete input circuit
Mic E.I.N.
1
(22 Hz - 22 kHz)
@ 150 Ω source -129.0 dBu / -117.3 dBqp
input shortened -132.0 dBu / -122.0 dBqp
Distortion (THD+N) 0.007 % @ +4 dBu, 1 kHz, bandwidth 80 kHz
Gain range +10 dB to +50 dB
Max. input level +12 dBu (+32 dBu @ PAD)
Line input
Type electronically balanced
Gain range 0 dB to +40 dB (-20 dB to +20 dB @ PAD)
Max. input level +22 dBu
Channel fader range +10 dB to -85 dB / off
Aux send gain range 0 dB to +15 dB / off
Equalizer
Hi shelving 12 kHz, ±15 dB
Hi mid sweep 300 Hz to 20 kHz, ±15 dB
Lo mid sweep 50 Hz to 3 kHz, ±15 dB
Lo shelving 80 Hz, ±15 dB
Lo cut (HPF) 75 Hz, 12 dB/oct.
Channel direct out
Max. output level +22 dBu
Noise @ 0 dB gain -94 dBu
Output impedance 120 Ω
Tape returns ¼" jacks, balanced / unbalanced, globally switchable from +4 dBu to -10 dBV
Channel inserts
Max. in/out +22 dBu
Channel to channel crosstalk -95 dB @ 1 kHz
Mix B channel strip
Gain range 0 dB to +15 dB / off
Hi shelving 12 kHz, ±15 dB
Lo shelving 80 Hz, ±15 dB
Subgroup section
Noise
2
bus noise @ fader 0 dB -102.5 dBr
24 chs. assigned (input B) & set @ 0 dB gain -92.5 dBr
16 chs. assigned (input B) & set @ 0 dB gain -94.5 dBr
Submaster output max. output level +22 dBu, balanced / unbalanced
Submaster insert max. output level +22 dBu
Submaster insert max. input level +22 dBu
Fader range +10 dB to -85 dB / off
Main mix section
Noise
2
bus noise @ fader 0 dB -101.0 dBr
24 chs. assigned (input B) & set @ 0 dB gain -92.5 dBr
16 chs. assigned (input B) & set @ 0 dB gain -94.5 dBr
Max. output level +28 dBu, XLR connector, balanced / +22 dBu, ¼" jacks, unbalanced
Aux returns gain range 0 dB to +20 dB / off
Aux sends max. output level +22 dBu
System data
Distortion (THD+N) 0.007 % @ +4 dBu, 1 kHz, bandwidth 80 kHz;
< 0.02 %, 22 Hz to 22 kHz at normal operating levels, any input to any output, bandwidth 80 kHz
Frequency response
20 Hz to 40 kHz ±1 dB (any input to any output)
10 Hz to 120 kHz ±3 dB
Noise
2
@ fader 0 dB -102.5 dBr
24 chs. assigned (input B) & set @ 0 dB gain -92.5 dBr
16 chs. assigned (input B) & set @ 0 dB gain -94.5 dBr
Power supply
Power consumption 250 W
Mains voltage 100 - 240 V~ (50/60 Hz)
Fuse T 3.15 A H 250 V
Mains connector standard IEC receptacle
Physical/weight
Dimensions (H x W x D) approx. 2.8"/8.7" x 37" x 29.5" (approx. 72 mm/220 mm x 940 mm x 750 mm)
Weight approx. 61.2 lb. (approx. 27.72 kg)
1
Equivalent Input Noise
2
ref. +4 dBu
