OWNER'S MANUAL
AA35 MIXER AMPLIFIER
2
TABLE OF CONTENTS
Safety Instructions.............................................................………………………………….………………….2
Introduction, Features, and Applications......................................................................……………………...3
Safety Precautions…………………………………………………………………………………………………..4
Front Panel Description......................................................................…………………………………..…….6
Rear Panel Description......................................................................…………………………………..……..7
Quick Start Examples……………………………………………………………………………………...……...12
Wiring the AA35……………………………………………………………………………………………………16
Rack Mounting Options……………………………………………………………………………………………17
Signal Path Block…………………………………………………………………………………………………..18
Input Transformer Installation………………………………………………………………………………........19
Specifi cations..........................................................................................…………………………………….20
Notes……………………………………………………………………………………………………………......21
Warranty................................................................................................……………………………………...24
SAFETY INSTRUCTIONS
Please Read Carefully Before Installing or Operating This Product
Read instructions fully.
Pay attention to any and all warnings.
Connect this amplifi er only to the correct operating voltage.
Do not attempt to service this unit. Only a qualifi ed service technician should open this unit for
servicing.
Warning - To reduce the risk of fi re or electric shock, do not expose this appliance to rain or moisture.
Do not install this device in dusty or humid locations, or in direct exposure to sunlight. In addition,
locations that have steam or sooty conditions are not to be used, as this may result in fire or electric
shock.
Protect the power cord from damage, pinching, or being walked on, in particular, the plug and the
cord attachment to the amplifier.
Do not defeat the polarized or grounding feature of the power cord plug. If the plug will not fit in your
outlet, consult a licensed electrician.
Use only the specified accessories and attachments specified in this manual.
Disconnect the power cord during electrical storms, or when the product will be unused for long
periods.
Have servicing done only by qualified personnel. Servicing will be required when the product is
damaged in any way, when the power cord is damaged, when liquid has been spilled or objects have
fallen into the device. Servicing will also be required when this device has been exposed to rain, does
not operate normally, or has been dropped.
