RADIO AND OTHER OPERATIONS
AM/FM RADIO
1. Press the ON/OFF button.
2. Switch Function Selector to RADIO position.
3. Switch Band Selector to either AM or FM radio position.
4. Turn tuning knob to select desired station as indicated on dial.
5. Adjust Master Volume to the desired level.
6. To turn the radio off, set Function Selector to iPod, CDG or AUX position.
SING ALONG - RADIO
1. Follow operating instructions for AM/FM radio.
2. Connect the supplied Microphone to either one of the Mic input jacks.
3. Adjust Master Volume and Mic Volume. Your voice will be combined with the radio
station output and will be heard through the speakers.
PUBLIC ADDRESS - USING A MICROPHONE
The unit can be used as a PA (Public Address System).
Public Address (PA) Operation Procedures
1. Connect the supplied Microphone to either one of the MIC input jacks.
2. Press the ON/OFF button to turn the unit on.
3. Set the Function Selector to AUX. Move the MIC VOLUME control to central position.
4. Move the ON/OFF switch located on the Microphone to the ON position and speak or
sing into the Microphone. The Microphone sensitivity and loudness could be adjusted as
required by turning the MIC VOLUME control and/or MASTER VOLUME control.
5. To add depth or ambiance to your voice, adjust the ECHO control until the desired effect
is obtained.
Note: To prevent feedback or whistling from occurring, please be sure that the
microphone is not too close to the unit.
1) Open the battery compartment.
2) Place a 9V battery in the compartment as indicated by the polarity symbols (+ and -) marked
inside the compartment of the wireless microphone.
NOTE: 9V battery is not included.
3) Close the battery compartment.
4) The wireless microphone has three settings:
1. ON - The switch is in the top position. The microphone will function. The red indicator
illuminates.
2. STANDBY - The switch is in the middle position. The microphone will not function. The
red indicator illuminates.
NOTE: The purpose of this setting is to maintain a connection between the microphone
and the Singing Machine when moving around the area in which it is being used. (This
function could also be considered a mute function)
3. OFF - The switch is in the bottom position. The microphone will not function. The red
indicator light is off.
NOTE: To ensure long battery life, please make sure that the wireless microphone is set to the
OFF position when not in use. When not in use for a long period of time, we recommend
that you remove the DC 9-V battery.
SMM-107A WIRELESS MICROPHONE OPERATION
E19
ENGLISH
