LA, Line Attributes
22-15
LA, Line Attributes
Specifies how line ends and line joins are physically shaped. Use this
command when drawing lines thicker than 0.35 mm.
LA
kind,value[,kind,value[,kind,value;]]
or
LA
[;]
Table 22-7
Related Commands Group
LA, Line Attributes
The Line and Fill Attributes Group
LT,Line Type
PW,Pen Width
RF,Raster Fill Definition
FP, Fill Polygon
The Polygon Group
RA, Fill Rectangle
Absolute
RR, Fill Rectangle Relative
WG, Fill Wedge
CF, Character Fill Mode
The Character Group
SV, Screened Vectors
The Line and Fill Attributes Group
Parameter Format Functional Range Default
kind clamped integer 1 through 3 1
value clamped integer Kind 1: 1 - 4 1 (Butt)
clamped integer Kind 2: 1 - 6 1 (Mitered)
clamped real Kind 3: 1 to 32,767 5
