Aviom A-16R and A-16CS User Guide
SOX 1111
0000
(F0H) Start of Exclusive
Manufacturer’s
ID
0000
0000
(00H) Aviom Manufacturer’s ID
Byte 1
0000
0001
(01H) Aviom Manufacturer’s ID
Byte 2
0100
0101
(45H) Aviom Manufacturer’s ID
Byte 3
Family ID 0000
0000
(00H) (A16 Family)
Product ID 0000
0000
(00H) (A-16R Product)
Device ID 0000
0000
(00H) (expansion)
Msg. Type 0000
0000
(00H) Message Type = MIDI_ALL_
PRESETS_MSG
Msg. Descriptor
0000
0000
(00H)
Message Descriptor Byte 1
(expansion)
0000
0000
(00H) Message Descriptor Byte 2
(expansion)
0000
0000
(00H) Message Descriptor Byte 3
(expansion)
0000
0000
(00H) Message Descriptor Byte 4
(expansion)
0000
0000
(00H) Message Descriptor Byte 5
(expansion)
0000
0000
(00H) Message Descriptor Byte 6
(expansion)
Preset ID 0001
0000
(10H) Nibblized First Preset ID
(MSB)*
0001
0000
(10H) Nibblized First Preset ID
(LSB)*
Preset Data ... ... 112 consecutive bytes
containing info for one preset
Preset
Checksum
0001
nnnn
- Nibblized Preset Data
Checksum (MSB)
0001
nnnn
- Nibblized Preset Data
Checksum (LSB)
Preset Trailer 0100
0000
(40H) Indicates end of a given preset
Padding ... ... 500 consecutive bytes of the
pattern 00H
