Specications
10
Specications
PREAMP SECTION
Valves
Type 1 x 12AX7A
1 x 12AX7B
2 x 12AX7C
Preamp high-gain input
Impedance 470 kΩ
Clean channel
Nominal input level -20 dBV
Min. input level -30 dBV
Max. input level 0 dBV
Crunch channel
Nominal input level -80 dBV
Min. input level -90 dBV
Lead channel
Nominal input level -80 dBV
Min. input level -90 dBV
Preamp low-gain input (only 333XL and 333XL-212)
Impedance 44 kΩ
All levels attenuated by +6 dB
Effects send
Impedance 47 kΩ or higher
Min. output level -10 dBV, 300 mV RMS
Max. output level 0 dBV, 1 V RMS
Effects return
Impedance 470 kΩ
Min. input sensitivity -10 dBV
Max. input sensitivity 0 dBV
Line output
Impedance 47 kΩ or higher
Adjustable output level ±20 dBV
POWER AMPLIFIER SECTION
Valves
Type 4 x 6L6GC (333 and 333-212)
4 x EL34 (333XL and 333XL-212)
Output power
Peak power 120 W / 16, 8, 4 Ω
Loudspeaker connectors
Type ¼" mono jack connectors, unbalanced
Load impedance 4 Ω / 8 Ω / 16 Ω switchable
Internal loudspeakers (only 333XL-212 and 333-212)
Type 2 x 12" BUGERA, 12G70J8
Impedance 8 Ω
Continuous power 70 W (IEC)
Total impedance 16 Ω (series connection)
POWER SUPPLY
U.S./Canada 120 V~, 60 Hz
China 220 V~, 50 Hz
Korea 220 V~, 60 Hz
Europe/U.K./Australia 230 V~, 50 Hz
Japan 100 V~, 50/60 Hz
General export model 120/230 V~, 50/60 Hz
Power consumption Max. 350 W
Fuse T 3.15 A H 250 V (100 – 120 V~, 50/60 Hz)
T 1.6 A H 250 V (220 – 230 V~, 50/60 Hz)
Mains connection Standard IEC receptacle
DIMENSIONS/WEIGHT
333
Dimensions (H x W x D) Approx. 9 25/32" x 27" x 9 11/16" (249 mm x 687.3 mm x 246 mm)
Weight Approx. 47 lbs (21.5 kg)
333-212
Dimensions (H x W x D) Approx. 20 13/32" x 27" x 9 3/4" (518.46 mm x 687.3 mm x 247.65 mm)
Weight Approx. 63 lbs (28.5 kg)
333XL
Dimensions (H x W x D) Approx. 9 25/32" x 27" x 9 11/16" (249 mm x 687.3 mm x 246 mm)
Weight Approx. 47 lbs (21.5 kg)
333XL-212
Dimensions (H x W x D) Approx. 20 13/32" x 27" x 9 3/4" (518.46 mm x 687.3 mm x 247.65 mm)
Weight Approx. 63 lbs (28.5 kg)
We are constantly striving to maintain the highest professional standards. As a result of these efforts, modications may be made from time to time to
existing products without prior notice. Specications and appearance may differ from those listed or illustrated.
