OMB-DAQ-2416-4AO User's Guide Specifications
31
Table 8. S type thermocouple accuracy specifications, including CJC measurement error.
All specifications are (±).
A/D data rate
Sensor
temperature range
Accuracy error
maximum
Accuracy error
typical
Tempco
(°C/°C)
3750 S/s
-50 °C
4.510 °C
2.930 °C
0.088
250 °C
2.165 °C
1.468 °C
1768 °C
3.187 °C
2.597 °C
2000 S/s
-50 °C
4.510 °C
2.930 °C
0.088
250 °C
2.165 °C
1.468 °C
1768 °C
3.187 °C
2.597 °C
1000 S/s
-50 °C
4.510 °C
2.930 °C
0.088
250 °C
2.165 °C
1.468 °C
1768 °C
3.187 °C
2.597 °C
500 S/s
-50 °C
3.798 °C
2.226 °C
0.088
250 °C
1.853 °C
1.156 °C
1768 °C
2.922 °C
2.332 °C
100 S/s
-50 °C
3.798 °C
2.226 °C
0.088
250 °C
1.853 °C
1.156 °C
1768 °C
2.922 °C
2.332 °C
60 S/s
-50 °C
3.798 °C
2.226 °C
0.088
250 °C
1.853 °C
1.156 °C
1768 °C
2.922 °C
2.332 °C
50 S/s
-50 °C
3.798 °C
2.226 °C
0.088
250 °C
1.853 °C
1.156 °C
1768 °C
2.922 °C
2.332 °C
25 S/s
-50 °C
3.798 °C
2.226 °C
0.088
250 °C
1.853 °C
1.156 °C
1768 °C
2.922 °C
2.332 °C
10 S/s
-50 °C
3.798 °C
2.226 °C
0.088
250 °C
1.853 °C
1.156 °C
1768 °C
2.922 °C
2.332 °C
5 S/s
-50 °C
3.798 °C
2.226 °C
0.088
250 °C
1.853 °C
1.156 °C
1768 °C
2.922 °C
2.332 °C
2.5 S/s
-50 °C
3.798 °C
2.226 °C
0.088
250 °C
1.853 °C
1.156 °C
1768 °C
2.922 °C
2.332 °C
To achieve the thermocouple accuracies listed above, the OMB-DAQ-2416-4AO should be warmed up for
45 minutes after the initial power on. The accuracies listed above are only guaranteed if the OMB-DAQ-2416-
4AO is housed in its plastic enclosure.
