The SC FILTER switch activates a high-pass filter in the side-chain path and thus limits the influence of
low frequencies on the AUTOCOM PROs control processes.
16
The 12-digit GAIN REDUCTION meter indicates how effectively the gain is reduced by the compressor,
within a range from 1 to 30 dB.
17
The 12-digit INPUT/OUTPUT LEVEL meter informs you - depending on the setting of the I/O METER
switch - about the current input or output level, within a range from -30 to +18 dB. When the switch is set
to IN (not engaged), the meter reads the input level, when it is OUT, the output level is displayed. The
meter is referenced to the operating level (-10 dBV or +4 dBu) adjusted with the OPERATING LEVEL
switch.
4.3 Dynamic Enhancer Section
18
Fig. 4.4: Control elements of the dynamic enhancer section
18
The PROCESS control sets the available amount of enhancement between Off and 6. Dynamic en-
hancement allows you to replenish any high frequencies lost through the compression process for
absolutely natural sounding dynamics control. Enhancement is only added when compression is taking
place.
4.4 Rear-Panel Control Elements Of The AUTOCOM PRO
