Save/Load of Song data (VF80EX)
Press the [SETUP] key to enter the setup mode.
The display shows the screen for selecting the setup
menu.
Use the [JOG] dial to select (highlight) “Load PGM”
and press the [ENTER/YES] key.
The display shows the screen for selecting a load de-
vice, where “IDE” is flashing.
Loading backup data from a CD-R/RW drive
<Note>
Do not carry out any VF80EX key operation until
the access process to the CD-RW/CD-R disc is com-
pleted.
<Note>
If you load song data which is saved to more
than one disc, set DISC-1 first.
If you set the other disc and go on the follow-
ing procedure, the VF80EX automatically rec-
ognized that the disc order i s not correct and
the display shows
“Wrong Disk”
, followed by
“Illegal No!”
momentarily, and the disc is au-
tomatically ejected.
After turning on the VF80EX, insert the disc to the
CD-R/RW drive.
While the desired backup number/title is shown on
the display, press the [ENTER/YES] key.
The display shows the screen for creating a new pro-
gram on the current drive, to which data will be loaded
(“New PGM” lights).
When you load song data which is saved to more
than one disc, the display also shows the disc num-
ber currently set. The example below shows DISC-
1 is set.
By rotating the [JOG] dial, you can select a desired
program number/title from among available programs
in the VF80 current drive. You can also select “Eject”.
If you select “Eject” and press the [ENTER/YES] key,
the disc is ejected
Flashing
Flashing
Light up
The following description is assumed that you have a CD-RW/CD-R disc which contains saved data.
While “IDE” is flashing, press the [ENTER/YES] key.
After briefly showing the model name of the connected
CD-R/RW drive, the display shows the screen for se-
lecting a load mode, where “BkUp” (backup) is flash-
ing.
To load song data saved, select “BkUp”.
To load a material from an audio CD, select “CD-DA”.
This procedure describes how to load song data, so
we select “BkUp” here.
See “Loading from an audio CD” described later for de-
tails about how to load a material from an audio CD.
Flashing
While “BkUp” is flashing, press the [ENTER/YES] key.
The display shows the backup number and title, as
well as recorded space.
Flashing
1
2
3
4
5
6
