25
USB Functions and System Functions
System Parameter Functions
Parameter Range Explanation
LCD Contrast -20–+20 Adjusts the contrast of the text in the screen.
Local Ctrl OFF, ON Refer to “Local Ctrl (Local Control)” (p. 26).
Master Tune 427.4–452.6 Hz Adjusts the tuning of the entire GW-7. The displayed value is the frequency of the A4 key (middle A).
Transpose -12–+12 Transposes the pitch of the GW-7 in semitone steps.
Trans Mode INT,
SNG,
I+S,
MID,
I+M,
S+M,
ALL
Selects the part(s) that will be affected by the above Transpose setting.
INT
: Only the keyboard part. Notes received from the MIDI IN connector will not be affected.
SNG
: Only the song parts will be transposed.
I+S
: The keyboard part and song part.
MID
: Only notes received from the MIDI IN connector will be transposed.
I+M
: The keyboard part and notes received from the MIDI IN connector.
S+M
: The song parts and notes received from the MIDI IN connector will be transposed.
ALL
: All parts and notes received from the MIDI IN connector will be transposed.
P.Bend Range 0–24 Specifies the range of pitch change that can be controlled using the pitch bend controller. (p. 17)
Pedal EXPRESSION,
CHORD OFF,
CHORD TGL,
SOSTENUTO,
SOFT,
ROTARY S/F,
START/STOP,
BASS INV,
PUNCH I/O
Selects the function that will be controlled when you press a separately available pedal connected to the CONTROL PED-
AL jack.
EXPRESSION
: The pedal will function as an Expression pedal.
CHORD OFF
: While you keep the pedal depressed, the Chord Assignment function in the left-hand region of the key-
board will be turned off, allowing you to play using the entire keyboard.
CHORD TGL
: When you press the pedal once, the Chord Assignment function for the left-hand region of the keyboard
will be turned off, allowing you to play using the entire keyboard. When you press the pedal again, the
keyboard will revert to its previous state, and you can use the left-hand region to specify chords.
SOSTENUTO
: The pedal will function as a Sostenuto pedal. When you press the pedal, notes that are already being held
down will be sustained. (This function can be used only for the keyboard part.)
SOFT
: The pedal will function as a Soft pedal. Notes you play while holding down the pedal will have a softer tone. (This
function can be used only for the keyboard part.)
ROTARY S/F
: The pedal will switch the speed of the rotary effect. This is valid only if the
ROTARY
type is selected for
MFX. (p. 20)
START/STOP
: The pedal will start/stop the backing or song playback.
BASS INV
: The pedal will switch the Bass Inversion function on/off. (p. 18)
PUNCH I/O
: The pedal will control punch-in and punch-out during song recording. (p. 22)
Pedal Pol STD, RVS Switches the polarity of the pedal connected to the CONTROL PEDAL jack. Some pedals will operate in the opposite of
the expected way when you press them. If you’re using this type of pedal, set this parameter to RVS (reverse). If you’re
using a Roland pedal (without a polarity switch), use the STD (standard) setting.
Hold Pol STD, RVS Switches the polarity of the pedal connected to the HOLD PEDAL jack. (* See “Pedal Pol,” above)
C1 REVERB SEND,
CHORUS SEND,
PORTA SW,
PORTA TIME,
DECAY TIME,
VIB RATE,
VIB DEPTH,
VIB DELAY
Choose the
EFFECT
to be controlled when you press [SELECT] to choose REVERB and then turn the C1 knob.
REVERB SEND
: Adjusts the send level of each tone to the reverb.
CHORUS SEND
: Adjusts the send level of each tone to the chorus.
PORTA SW
: Portamento will be applied if you turn the knob to the right, and will not be applied if you turn the knob
to the left. (p. 12)
PORTA TIME
: Adjusts the portamento time. Turn toward the right to lengthen the time. (p. 12)
DECAY TIME
: Adjusts the decay time. Turn toward the right to lengthen the time. (p. 12)
VIB RATE
: Adjusts the modulation speed of vibrato. Turn toward the right to make the vibrato faster. (p. 12)
VIB DEPTH
: Adjusts the modulation depth of vibrato. Turn toward the right to make the vibrato deeper. (p. 12)
VIB DELAY
: Adjusts the amount of time to pass before vibrato begins. Turn toward the right to lengthen the delay. (p. 12)
C2 Same as “C1”
above
Choose the
EFFECT
to be controlled when you press [SELECT] to choose CHORUS and then turn the C2 knob.
Split Ctrl OFF, ON Selects whether the controllers (hold pedal, control pedal, pitch bend/modulation) will apply to the Lower Part of Split
mode.
Metro Time 1/4, 2/4, 3/4, 4/4,
5/4, 6/4, 6/8, 9/8
Specifies the time signature (the number of beats per measure) for the metronome. (p. 10)
Metro Vol 0–127 Adjusts the volume of the metronome. (p. 10)
MIDI TxRx ALL, KBD, STL,
SNG, OFF
Refer to “MIDI TxRx (MIDI Transmission/Reception)” (p. 26).
Sync Rx OFF, ON Refer to “Sync Rx (MIDI Synchronization)” (p. 26).
P.Bend TxRx OFF, ON Refer to “P.Bend TxRx (Pitch Bend Message Transmission/Reception)” (p. 27).
Mod TxRx OFF, ON Refer to “Mod TxRx (Modulation Message Transmission/Reception)” (p. 27).
Prog TxRx OFF, ON Refer to “Prog TxRx (Program Change Message Transmission/Reception)” (p. 27).
Velocity Rx OFF, ON Refer to “Velocity Rx (Velocity Reception)” (p. 27).
Clock Tx OFF, ON Refer to “Clock Tx (Clock Message Transmission)” (p. 27).
StartStop Tx OFF, ON Refer to “StartStop Tx (Start/Stop/Continue Message Transmission)” (p. 27).
SongPos TxRx OFF, ON Refer to “SongPos TxRx (Song Position Pointer Message Transmission/Reception)” (p. 27).
Lyrics Tx OFF, ON Refer to “Lyrics Tx (Lyrics Data Transmission)” (p. 27)
