Before You Start Playing
Connecting the Pedal Cord
Insert the pedal cord into the Pedal connector on the
rear panel of the HP107.
fig.00-01
Connecting the Speaker
Cable
As shown in the diagram, connect the speaker cable
leading from the speaker box of the stand to the
speaker connector located on the rear bottom of the
HP107.
Push the speaker cable in until it clicks into position.
NOTE
Do not put anything that contains water (e.g., flower vases) on
this unit. Also, avoid the use of insecticides, perfumes, alcohol,
nail polish, spray cans, etc., near the unit.
The speakers of this piano are mounted beneath the upper
surface, and face upwards. Malfunctions or accidents may occur
if liquids contact any part of the speakers.
Connect the Power Cord
1.
Insert the included power cord into the AC inlet on the
bottom panel of the HP107.
2.
Plug the power cord into a power outlet.
NOTE
Use only the attached power-supply cord.
fig.00-02
Setting Up the Music Rest
1.
Grasping the music rest with both hands, lift it toward
you until its in the upright position.
2.
Use the support on the back of the music rest to keep
the stand in place.
The angle of the music rest can be set to any of three
positions.
fig.mu_stand
■
Folding down the music rest
Raise the support located on the back of the music rest,
then gently fold down the music rest.
■
Using the music holders
You can use the holders to hold pages in place.
When not using the holders, leave them folded down.
fig.mu_stand4
Speaker cable
Speaker connector
Clip portion
Speakers
1
2
