Before You Start Playing
■
Removing the music rest
You can remove the music rest from the piano.
This allows you to place a notebook computer on the piano.
Position the music rest so it’s upright, then remove the
three screws, as shown.
You can remove the screws using a coin.
fig.mu_stand3
NOTE
Be careful not to lose the screws that you removed from the
music rest, or put them where they might be swallowed by
small children.
Opening/Closing the Lid
To open the lid, use both hands to lift it lightly, and
slide it away from yourself.
To close the lid, pull it gently toward yourself, and
lower it softly after it has been fully extended.
fig.00-05
NOTE
When opening and closing the lid, be careful not to let your
fingers get caught. If small children will be using the HP107,
adult supervision should be provided.
NOTE
If you need to move the piano, make sure the lid is closed first
to prevent accidents.
Connecting Headphones
The HP107 has two jacks for plugging in headphones. This
allows two people to listen through headphones
simultaneously, making it very useful for lessons and when
performing piano pieces for four hands. Additionally, this
allows you to play without having to worry about bothering
others around you, even at night.
Plug the headphones into the Phones jacks located at
the bottom left of the piano.
fig.00-04.e
When headphones are connected, the [ (Headphones)]
indicator (p. 10) lights up, and sounds stop playing from
the speakers of the HP107.
The headphone volume is adjusted by the [Volume]
knob (p. 14) of the HP107.
NOTE
Use Stereo headphones.
Make sure to use only Roland headphones. Headphones from
other manufacturers may be unable to provide sufficient
volume.
Some notes on using headphones
• To prevent damage to the cord, handle the headphones only by
the headset or the plug.
• Connecting the headphones when the volume of connected
equipment is turned up may result in damage to the
headphones. Lower the volume on the HP107 before plugging
in the headphones.
• Listening at excessively high volume levels will not only
damage the headphones, but may also cause hearing loss. Use
the headphones at a moderate volume level.
■
Using the headphones hook
Whenever you are not using the headphones, you can hang
them on the headphone hook at the lower left of the HP107.
Attaching the Headphone Hook
Press and twist the headphone hook included with the
HP107 into the hole in the bottom of the HP107 (refer to the
figure below). Turn the wing nut of headphone hook to
secure the headphone hook.
Phones jack x 2
Headphone Hook
Wing Nut
