14
Getting Ready to Play
Attaching the Rubber Feet
If you will not be using the separately available RAD-50 rack-mount
adaptor, attach the rubber feet that were supplied with the JV-1010, as
shown in the figure. Use the small holes on the bottom as a guide for
positioning the rubber feet when attaching them.
fig.1-01.e
Installing on the Rack-Mount Adaptor
When installing on the rack-mount adaptor (RAD-50; sold separately), use
the screw (M4 x 8) included with the rack-mount adaptor.
fig.1-02.e
affix the supplied rubber feet onto the bottom of the unit
Screw (M4 x 8)
When mounting the unit
using the rack-mount
adaptor, install it onto the
rack-mount adaptor
without attaching the
rubber feet.
