The Function Mode
The [FUNCTION] button provides access to a range of functions that give the
CLP-411/511 extraordinary versatility. The functions are categorized in groups
as follows:
CLP-411
CLP-511
F1 F1 Tuning ............................................................. 21
F2 F2 Scale ............................................................... 21
F3 F3 Dual Mode Functions .................................... 22
– F4 Split Mode Functions .................................... 23
F4 F5 Metronome Functions ................................... 25
F5 F6 Left Pedal Mode ............................................. 25
– F7 Piano Song Part Cancel Volume .................. 25
F6 F8 MIDI Functions ............................................... 26
– F9 Backup Functions.......................................... 29
To Select a Function … ...........................................................................
ZPress the [FUNCTION] button so that its indicator lights.
NOTE
• Functions cannot be selected during demo/piano song playback or when
the recorder is in operation.
CLP-511
TRANSPOSE SPLIT
CLP-411
TRANSPOSE
REVERB
HALL
2
STAGE
XUse the [<] and [>] buttons (i.e. the [TRANSPOSE] and [RE-
VERB] buttons on the CLP-411, or the [TRANSPOSE] and
[SPLIT] buttons on the CLP-511) to select the desired function: F1
through F9 on the CLP-511; F1 through F6 on the CLP-411.
CIn the case of the Dual Mode (F3), Split Mode (F4: CLP-511),
Metronome (F4: CLP-411, F5: CLP-511), MIDI (F6: CLP-411, F8:
CLP-511), and Backup (F9: CLP-511) functions, you will have to
press the [+/YES] button once to enter the respective sub-mode
after the function has been selected, and then use the [<] and [>]
buttons again to select the desired sub-function.
NOTE
• The Dual or Split (CLP-511) mode must be engaged before the F3 and
F4 functions can be selected, respectively. If the corresponding mode is
not engaged, “
F3.-
” or “
F4.-
” will appear on the display and the corre-
sponding sub-mode will not be available.
• The Dual mode can be engaged while in the Function mode, but the
Function mode must be exited before the Split mode (CLP-511) can be
engaged.
VSet the function as required by using the [–/NO] and [+/YES]
buttons (see the individual function descriptions, below).
BPress the [FUNCTION] button so that its indicator goes out to exit
from the function mode.
FUNCTION
● Operation Example
(sub-mode)
Press [+/YES]
Use [<], [>]
Use [–/NO], [+/YES]
Press [–/NO] or [+/YES]
once
