The Control Panel
1 [POWER] Switch
Press the [POWER] switch once to turn the power ON, a second time
to turn the power OFF. When the power is initially turned ON, a voice
selector LED will light, and the power indicator located below the left end
of the keyboard will light.
2 [MASTER VOLUME] Control
The [MASTER VOLUME] control adjusts the volume (level) of
sound produced by the Clavinova’s internal stereo sound system. The
[MASTER VOLUME] control also adjusts headphone volume when a
pair of headphones is plugged into the PHONES jack (page 5).
3 [FUNCTION] Button
This button accesses a range of utility functions — including the MIDI
functions — that significantly enhance versatility and playability. See
page 20 for details.
4 [TRANSPOSE] Button
The [TRANSPOSE] button allows access to the Clavinova’s TRANS-
POSE function (to shift the pitch of the entire keyboard up or down in
semitone intervals).
5 [SPLIT] Button (CLP-511)
Engages the split mode in the CLP-511, in which different voices can
be played on the left- and right-hand sections of the keyboard. See page 11
for details.
6 [REVERB] Button
The [REVERB] button selects a number of digital reverb effects that
you can use for extra depth and expressive power. See page 12 for details.
7 [EFFECT] Button
This button engages a chorus effect which can give your sound greater
depth and animation.
8 [TOUCH] Button
The [TOUCH] button makes it easy to adjust the touch response of the
Clavinova to match your playing style. See page 14 for details.
9 Voice Selectors & [VARIATION] Button
The CLP-411 has seven voice selectors and a [VARIATION] button,
and the CLP-511 has nine voice selectors and a [VARIATION] button.
Simply press any of the voice selectors to select the corresponding voice.
The voice selector LED will light to indicate which voice is currently
selected. Press the [VARIATION] button so that its indicator lights to
select a variation of the currently selected voice.
There is also a dual mode in which two voices can be played simulta-
neously across the full range of the keyboard (see page 10 for details), and
a split mode on the CLP-511 which allows different voices to be played
by the left and right hands (see page 11 for details).
B5 C6
D6 E6 F6 G6 A6 B6 C7
$ #
START
/
STOP
REC
12
RECORDER
B5 C6
D6 E6 F6 G6 A6 B6 C7
#
START
/
STOP
REC
RECORDER
