148 Appendix C Printer Memory and Expansion
EN
6 Remove the DIMM from the
antistatic package.
7 Holding the DIMM by the edges (as
shown in the illustration), align the
notches on the DIMM with the
DIMM slot. (Check that the locks on
each side of the DIMM slot are
open.)
Note
For best results use DIMM slots in 1-2
order.
8 Press the DIMM straight into the
slot (press firmly). Make sure the
locks on each side of the DIMM
snap inward into place. (To remove
a DIMM, the locks must be
released.)
Repeat steps 6, 7, and 8 for each
DIMM being installed.
9 To replace the side panel, line up
the alignment arrows and slide the
panel backwards until the release
button latches into place. Close the
top cover.
10 Reinstall the interface cable(s) and
power cord. Turn the printer on.
7
8
6
9
10
