Level meter features
Level meter
Each input includes a five-segment LED meter for visually moni-
toring signal levels.This is essential for setting up and maintaining proper gain structure.
Peak indicator—PK
The input signal is monitored at several points throughout the channel.These points
are the mic preamp,the EQ stage and the fader stage.Overload at any of these stages will
cause the red peak-LED to light.
The channel gain should reduced if this occurs.
Signal level LEDs
These three LEDs light up at +8—yellow,0—green,and -6 dB—green.This level range
-6 to +8 is the optimum operating range. Compressed or relatively constant signals should
remain close to 0.
Signal present indicator—SIG
This green-LED varies in brightness in response to signal levels between -40 dB and -
6 dB.
LED
LED
LED
LEDLEDLEDLEDLED
